Product Main Mountain Bikes Santa Cruz Santa Cruz Mountain Bikes Santa Cruz 5010 2018 Santa Cruz 5010

2018 Santa Cruz 5010 Carbon C R Bike (discontinued)

Views:

Discontinued

Santa Cruz 5010 Carbon R Gloss SIracha and Black

Santa Cruz

Edit Tags Done

Create New Tag

Error

Edit Tags Done

Where To Buy
	Free shipping on orders of $99 or more (U.S. only). Free international shipping available with minimum order values. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free standard shipping on all bikes (contiguous U.S. only). Flat rate shipping to Hawaii and Alaska.	No match. Browse other Mountain Bikes
	Buy direct from the manufacturer	No match. Browse other Mountain Bikes
	Free shipping on complete bike purchases (continental U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping and free 100-day returns on all U.S. orders. Shipping available to North America, Canada, and Europe (including Switzerland).	No match. Browse other Mountain Bikes
	Free standard shipping on orders over $49.	No match. Browse other Mountain Bikes
	Free shipping on orders over $75 (contiguous U.S. only). Shipping available to Alaska, Hawaii, Guam, Virgin Islands, and Puerto Rico.	No match. Browse other Mountain Bikes
	Free standard shipping on orders of $50 or more (U.S. only). International shipping available. Free on orders of $150 or more. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free ground shipping and free returns on orders of $50 or more (continental U.S. only)	No match. Browse other Mountain Bikes
	Free shipping on orders over $75 (contiguous U.S. only). Free international shipping available with minimum order values. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free U.S. shipping on everything. International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on orders over $50 (contiguous U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on orders over $70 (contiguous U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free ground shipping on orders over $50 (U.S. only).	No match. Browse other Mountain Bikes

Compare to other Bikes

Need more info? View our Trail Mountain Bikes buyer's guide.

Specifications

Product

Santa Cruz 5010 Carbon C R Bike

Model Year

2018

Riding Type

Trail

Rider

Unisex

Sizes and Geometry

S, M, L, XL View Geometry

Size	S	M	L	XL
Top Tube Length	576mm	598mm	621mm	654mm
Head Tube Angle	67°	67°	67°	67°
Head Tube Length	100mm	110mm	120mm	130mm
Seat Tube Angle	73.8°	73.8°	73.8°	73.8°
Seat Tube Length	395mm	420mm	450mm	495mm
Bottom Bracket Height	334mm	334mm	334mm	334mm
Chainstay Length	426mm	426mm	426mm	426mm
Wheelbase	1117mm	1141mm	1164mm	1198mm
Standover	711mm	717mm	719mm	732mm
Reach	405mm	425mm	445mm	475mm
Stack	585mm	595mm	604mm	613mm
* Additional Info	All measurements reflect installation of a fork with a 519mm axle-to-crown height

Wheel Size

27.5" (650b)

Frame Material

Carbon Fiber

Frame Material Details

Forged upper and lower links, full carbon dropouts and disc mounts, molded rubber chainstay and downtube protection, stealth and external seatpost cable routing

Rear Travel

130mm

Rear Shock

FOX Float Performance DSP

Fork

RockShox Recon RL

Fork Travel

130mm

Head Tube Diameter

Tapered

Headset

Cane Creek 10, zero stack

Handlebar

Race Face Ride, 35mm diameter, 760mm width

Stem

Race Face Ride, 50mm

Grips

Santa Cruz Palmdale, lock-on

Brakes

SRAM Level T with Avid Centerline 180mm rotors front and rear, 6-bolt

Brake Levers

SRAM Level T

Drivetrain

Shifters

SRAM NX, 11-speed

Front Derailleur

N/A

Rear Derailleur

SRAM NX, 11-speed

ISCG Tabs

ISCG 05

Chainguide

none

Cranks

Race Face Aeffect

Chainrings

32 tooth

Bottom Bracket

Standard, threaded

Pedals

none

Chain

SRAM PC1110

Cassette

SRAM XG1150, 11-speed, 10-42 tooth

Rims

WTB ST i15 TSC

Hubs

Front: Novatec D711, 15mm x 110mm, 28 hole
Rear: Novatec D462, 12mm x 148mm, 28 hole, XD Driver

Spokes

DT Swiss Competition (28)

Tires

Front: Maxxis Minion DHF, 2.3", EXO, TR
Rear: Maxxis Crossmark II, 2.25", EXO, TR

Saddle

WTB Volt Race

Seatpost

Race Face Aeffect

Seatpost Diameter

31.6mm

Seatpost Clamp

36.4mm, standard, single bolt

Rear Dropout / Hub Dimensions

12mm x 148mm

Max. Tire Size

2.5"

Bottle Cage Mounts

Bottle cage mount within front triangle

Colors

Gloss Siracha and Black, Gloss Ink and Black

Warranty

Lifetime frame warranty, lifetime bearing warranty

Weight

N/A

Miscellaneous

Double sealed pivots
Collet axle pivots
Dual grease ports on lower link
120mm - 140mm fork compatibility

Price

$3,899

More Info

www.santacruzbicycles.com
