Specifications

Product

Pivot Switchblade Pro X01 Bike

Model Year

2021

Intended Use

Trail

Enduro / All-Mountain

Rider

Unisex

Sizes and Geometry

XS (Low, High)

SM (Low, High)

MD (Low, High)

LG (Low, High)

XL (Low, High)

View Full Geometry

Size	XS (Low, High)	SM (Low, High)	MD (Low, High)	LG (Low, High)	XL (Low, High)
Top Tube Length	569mm, 568mm	592mm, 590mm	620mm, 619mm	638mm, 636mm	661mm, 660mm
Head Tube Angle	66.0°, 66.5°	66.0°, 66.5°	66.0°, 66.5°	66.0°, 66.5°	66.0°, 66.5°
Head Tube Length	85mm	90mm	102mm	108mm	120mm
Seat Tube Angle	75.5°, 76.0°	75.5°, 76.0°	75.5°, 76.0°	75.5°, 76.0°	75.5°, 76.0°
Seat Tube Length	343mm	368mm	394mm	432mm	470mm
Bottom Bracket Height	346mm, 352mm	346mm, 352mm	346mm, 352mm	346mm, 352mm	346mm, 352mm
Chainstay Length	431mm, 430mm	431mm, 430mm	431mm, 430mm	431mm, 430mm	431mm, 430mm
Wheelbase	1147mm, 1146mm	1169mm, 1168mm	1193mm, 1192mm	1216mm, 1215mm	1241mm, 1240mm
Standover	648mm, 654mm	668mm, 673mm	694mm, 699mm	696mm, 701mm	700mm, 706mm
Reach	410mm, 415mm	430mm, 435mm	455mm, 460mm	470mm, 475mm	490mm, 495mm
Stack	610mm, 606mm	614mm, 611mm	625mm, 621mm	630mm, 627mm	641mm, 638mm
Additional Info	Geometry adjustable via flip chip in upper linkage.

Sizes Additional Info

Geometry adjustable via flip chip in upper linkage.

View Full Geometry

Size	XS (Low, High)	SM (Low, High)	MD (Low, High)	LG (Low, High)	XL (Low, High)
Top Tube Length	569mm, 568mm	592mm, 590mm	620mm, 619mm	638mm, 636mm	661mm, 660mm
Head Tube Angle	66.0°, 66.5°	66.0°, 66.5°	66.0°, 66.5°	66.0°, 66.5°	66.0°, 66.5°
Head Tube Length	85mm	90mm	102mm	108mm	120mm
Seat Tube Angle	75.5°, 76.0°	75.5°, 76.0°	75.5°, 76.0°	75.5°, 76.0°	75.5°, 76.0°
Seat Tube Length	343mm	368mm	394mm	432mm	470mm
Bottom Bracket Height	346mm, 352mm	346mm, 352mm	346mm, 352mm	346mm, 352mm	346mm, 352mm
Chainstay Length	431mm, 430mm	431mm, 430mm	431mm, 430mm	431mm, 430mm	431mm, 430mm
Wheelbase	1147mm, 1146mm	1169mm, 1168mm	1193mm, 1192mm	1216mm, 1215mm	1241mm, 1240mm
Standover	648mm, 654mm	668mm, 673mm	694mm, 699mm	696mm, 701mm	700mm, 706mm
Reach	410mm, 415mm	430mm, 435mm	455mm, 460mm	470mm, 475mm	490mm, 495mm
Stack	610mm, 606mm	614mm, 611mm	625mm, 621mm	630mm, 627mm	641mm, 638mm
Additional Info	Geometry adjustable via flip chip in upper linkage.

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

Full Hollow Core Carbon, size-specific optimized, molded chainstay and down tube protection

Rear Travel

142mm

Rear Shock

FOX FLOAT DPX2 Factory, 185mm x 55mm
Optional upgrade: FOX Live Valve Factory

Fork

FOX FLOAT 36 Factory, GRIP2 damper, 44mm offset
Optional upgrade: FOX Live Valve Factory

Fork Travel

160mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Pivot Precision, sealed cartridge bearings

Handlebar

Phoenix Team Low Rise Carbon
Width: 760mm (XS), 780mm (SM/MD/LG), 800mm (XL)

Stem

Phoenix Team Enduro/Trail

Grips

Phoenix Factory, lock-on

Brakes

SRAM G2 RSC, 4-piston, SRAM CenterLine CENTER LOCK rotors (200mm front, 180mm rear)

Brake Levers

SRAM G2 RSC

Drivetrain

Shifters

SRAM X01 Eagle, 12-speed

Front Derailleur

None

Rear Derailleur

SRAM X01 Eagle, 12-speed

ISCG Tabs

ISCG05

Chainguide

None

Cranks

SRAM X01 Eagle DUB

Chainrings

SRAM X01 Eagle, 32 tooth

Bottom Bracket

SRAM DUB, PressFit BB92 (PF92)

Pedals

None

Chain

SRAM X01 Eagle, 12-speed

Cassette

SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth

Rims

DT Swiss M1700, 30mm width
Optional upgrade: DT Swiss XMC1501 Carbon with DT Swiss 240 hubs

Hubs

DT Swiss 350, 110x15mm Boost front, 157x12mm SuperBoost rear with 36-tooth Star Ratchet and XD driver
Optional upgrade: DT Swiss 240 hubs with DT Swiss XMC1501 Carbon rims

Spokes

DT Swiss wheelset

Tires

Front: Maxxis Minion DHF, 3C MaxxTerra, EXO+, TR, 29" x 2.5" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra, EXO+, TR, 29" x 2.4" WT

Saddle

XS/SM: Phoenix WTB Pro High Tail Trail
MD/LG/XL: Phoenix WTB Pro Vigo

Seatpost

FOX Transfer Factory dropper
Drop: 125mm (XS), 150mm (SM), 175mm (MD/LG/XL)

Seatpost Diameter

30.9mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

157x12mm SuperBoost

Max. Tire Size

29" x 2.6" or 27.5" x 2.8"

Bottle Cage Mounts

One inside front triangle (on all sizes) plus one underneath down tube; additional accessory mounts under top tube

Colors

Horizon Blue, Treeline Green

Warranty

10 years frame, 1 year paint and finish, 5 years Phoenix components

Weight

N/A

Miscellaneous

dw-link suspension design
Geometry adjustable via flip chip in upper linkage
Compatible with 27.5+ wheels
Cable Port System internal cable routing

Price

With DT Swiss M1700 rims and 350 hubs: $7,299.00

With DT Swiss XMC1501 rims and 240 hubs: $8,599.00

With FOX Live Valve DT Swiss M1700 rims and 350 hubs: $9,199.00

With FOX Live Valve DT Swiss XMC1501 rims and 240 hubs: $10,499.00

More Info

pivotcycles.com
