2013 Pivot Mach 4 with XX-1 (discontinued)

Views:
Discontinued
2013 Pivot Mach 4 with XX-1  bike - Pivot MACH 4 (black with Shimano XTR)
C70_bike_pivot_mach_4_black_with_shimano_xtr C70_bike_pivot_mach_4_blue_with_sram_x9 C70_xt C70_xtr_pro
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications

Product Pivot Mach 4 with XX-1
Model Year 2013
Riding Type Cross Country
Rider Unisex
Sizes and Geometry
XXS, XS, S, M, L, XL View Geometry
Size XXS XS S M L XL
Top Tube Length 20.8 22.25 22.75 23.25 24 24.6
Head Tube Angle 68.5° 68.7° 69.2° 69.2° 69.7° 69.7°
Head Tube Length 3.5 4 4.25 4.5 5.5 6.1
Seat Tube Angle 72.7° 72.2° 71.7° 71.7° 71.7° 71.7°
Seat Tube Length 14.25 15.75 17.2 18.5 20 21.5
Bottom Bracket Height 13.2 13.17 13.17 13.17 13.17 13.17
Chainstay Length 16.75 16.75 16.75 16.75 16.75 16.75
Wheelbase 41.07 42.33 42.43 42.94 43.74 44.36
Standover 25.9 26.9 28.9 29.15 29.15 29.9
Reach 14.4 15.59 15.78 16.21 16.66 17.08
Stack 20.71 21.23 21.57 21.81 22.76 23.33
Wheel Size
Frame Material Aluminum
Frame Material Details
Rear Travel 100mm
Rear Shock Fox Float CTD Kashima
Fork Fox F120 Fit CTD Trail Adjust Kashima
Fork Travel 120mm
Head Tube Diameter 1.5" Tapered Zero Stack
Headset Pivot Precision Sealed Bearing
Handlebar Phoenix Carbon Riser 740mm
Stem Syntace F109
Grips Pivot Lock On
Brakes Magura MT-8
Brake Levers Magura MT-8
Drivetrain 1x
Shifters Sram XX-1 Rear
Front Derailleur N/A
Rear Derailleur Sram XX-1 11-Speed
ISCG Tabs
Chainguide
Cranks Sram XX-1 GXP
Chainrings 30 Tooth
Bottom Bracket Sram Press Fit 92mm Wide
Pedals N/A
Chain
Cassette Sram XX-1 10-42 Tooth 11-Speed
Rims DT 400
Hubs DT 240
Spokes DT Aerolite
Tires Kenda Slant 6, 2.1"
Saddle WTB Volt Team
Seatpost Syntace P6 Carbon
Seatpost Diameter 30.9mm
Seatpost Clamp
Rear Dropout / Hub Dimensions 142mm x 12mm
Max. Tire Size
Bottle Cage Mounts Yes
Colors Anodized Jet Black, Anodized Cobalt Blue, Alpine White with Blue/Black Decals, or Alpine White/Pink (Women’s)
Warranty
Weight 21 lb 9.7 oz (9800 g)
Miscellaneous
Price $6,499
More Info Pivot website
