2022 Pivot Mach 4 SL Ride SLX/XT Bike
(discontinued)

Discontinued
s1600 photo 647911.jpg?VersionId=yx7Tzx8QIdP
c70 photo 647911.jpg?VersionId=EGhZ5n
c70 photo 176834
s1600 photo 647911.jpg?VersionId=yx7Tzx8QIdP s1600 photo 176834
Related:
Pivot
Where To Buy
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.
$7,499.00
Free shipping on orders over $50 (contiguous U.S. only).
International shipping available. Some exclusions apply.
Free U.S. shipping on everything.
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Pivot Mach 4 SL Ride SLX/XT Bike
Model Year
2022
Intended Use
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
XS
SM
MD
LG
XL
View Full Geometry
Sizes Additional Info

Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
Hollow Core Molding Technology Carbon front and rear triangles; cold-forged alloy linkages; molded chainstay, seatstay, and down tube protection
Rear Travel
100mm
Rear Shock
FOX FLOAT DPS Performance, 190mm x 40mm
Fork
FOX FLOAT 34 Step-Cast (SC) Performance, GRIP damper, 44mm offset
Fork Travel
120mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Pivot Precision, sealed integrated cartridge bearings
Handlebar
Phoenix Race Low Rise Aluminum, 780mm width
Stem
Phoenix Team XC/Trail
Grips
Phoenix Factory, lock-on
Brakes
Shimano SLX M7100, 2-piston, Shimano SLX 6-bolt 160mm rotors
Brake Levers
Shimano SLX M7100
Drivetrain
1x
Shifters
Shimano SLX M7100, 12-speed, I-SPEC EV bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SGS cage
ISCG Tabs
ISCG05 (front two inserts only)
Chainguide
None
Cranks
Race Face Ride
Chainrings
Race Face Ride, 32 tooth
Bottom Bracket
Press-fit BB92 (PF92)
Pedals
None
Chain
Shimano SLX M7100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Rims
DT Swiss X1900, 25mm width
Hubs
DT Swiss 370, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Spokes
DT Swiss wheelset
Tires
Maxxis Ardent Race, EXO casing, TR, 120 TPI, 29" x 2.2"
Saddle
Phoenix WTB Volt Race, narrow width
Seatpost
FOX Transfer Performance Elite dropper
Drop: 100mm (XS), 125mm (SM/MD/LG), 150mm (XL)
Seatpost Diameter
30.9mm
Seatpost Clamp
Single bolt, 34.9mm
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size
29" x 2.35-2.4"
Bottle Cage Mounts
One inside front triangle, plus accessory mounts under top tube (compatible with Pivot Dock Tool System)
Colors
Greystorm, Black Sunset
Warranty
10 years frame, 1 year paint and finish, 5 years Phoenix components
Weight

Miscellaneous
• dw-link rear suspension design
• Internal cable routing with Cable Port System
• SRAM UDH (Universal Derailleur Hanger)
• Frame weights start at 1845g
Price
$6,199.00
