2013 Pivot Firebird XO Bike (discontinued)

Average User Rating: (Spectacular)
Views:
Discontinued
2013 Pivot Firebird XO Bike Screen shot 2011-12-02 at 10.24.45 PM
C70_screen_shot_2011_12_02_at_10.24.45_pm C70_screen_shot_2011_12_02_at_10.24.35_pm C70_screen_shot_2011_12_02_at_10.24.26_pm C70_screen_shot_2011_12_02_at_10.24.54_pm C70_screen_shot_2011_12_02_at_10.25.02_pm
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes or Freeride Mountain Bikes buyer's guides.

Quiver Killer. One bike to rule them all

Rating:
The Good:

Pedals great, slays dh,

The Bad:

absolutely nothing

Overall Review:

This really is a do it all bike. Ive done everything from all day xc rides to shuttle dh runs with it. When setup correctly it pedals great. The DW link really is all its chalked up to be. WIth correct air pressure there is virtually no bob and it tracks very well. I run a talas 180/140 on mine and in 180 mode its like a mini DH sled. Holds its own against dual crown bikes but you can still pedal it to the top of the mountain if need be without a fuss. Can be built to sub 30 as well. Also excepts an angleset with that massive head tube.

Rate review: +1 Up Down
Vital MTB member DBomberMan
16745 DBomberMan https://p.vitalmtb.com/photos/users/16745/avatar/c50_p4pb8129885.jpg?1341017602 https://www.vitalmtb.com/community/DBomberMan,16745/all 06/29/12 https://www.vitalmtb.com/community/DBomberMan,16745/setup 1 25 1

Specifications

Product Pivot Firebird XO Bike
Model Year 2013
Riding Type Trail, Freeride
Rider Unisex
Sizes and Geometry
S, M, L, XL View Geometry
Size S M L XL
Top Tube Length 22.5 23 24 24.6
Head Tube Angle 67.1° 67.1° 67.1° 67.1°
Head Tube Length 4.6 4.8 5.5 6.1
Seat Tube Angle 71.1 71.1 71.1 71.1
Seat Tube Length 16.5 17.75 19 21
Bottom Bracket Height 13.98 13.98 13.98 13.98
Chainstay Length 17.25 17.25 17.25 17.25
Wheelbase 43.75 44.25 45.32 45.96
Standover 28.63 28.63 28.63 29.13
Reach 14.5 14.92 15.72 16.13
Stack 23.49 23.68 24.33 24.89
Wheel Size
Frame Material Aluminum
Frame Material Details
Rear Travel 167.6mm
Rear Shock Fox Float CTD Kashima
Fork Fox 36 170mm Float RC 32FIT Kashima
Fork Travel 170 mm
Head Tube Diameter 1.5
Headset Cane Creek Angleset
Handlebar Gravity Light OS 710mm
Stem FSA Gap
Grips Phoenix Lockon
Brakes Sram XO Trail
Brake Levers Sram XO Trail
Drivetrain
Shifters Sram XO
Front Derailleur New XT E-Type
Rear Derailleur Sram XO Type 2
ISCG Tabs ISCG 05
Chainguide MRP LRP
Cranks Sram X0 GXP AM
Chainrings 22/36
Bottom Bracket Sram
Pedals
Chain
Cassette XT M770 11-36 10Spd
Rims DT 500
Hubs DT 350
Spokes DT Supercomp
Tires Kenda Nevegal 2.35
Saddle WTB Vigo Race
Seatpost Gravity Light
Seatpost Diameter 30.9
Seatpost Clamp
Rear Dropout / Hub Dimensions 142 x 12
Max. Tire Size
Bottle Cage Mounts
Colors Black/White
Warranty
Weight N/A
Miscellaneous
Price $6,199
More Info Pivot website
