2017 Orange Five Pro Bike (discontinued)

Views:
Discontinued
2017_Orange_Five_Pro
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes buyer's guide.

Specifications

Product Orange Five Pro Bike
Model Year 2017
Riding Type Trail
Rider Unisex
Sizes and Geometry
XS, S, M, L, XL View Geometry
Size XS S M L XL
Top Tube Length 575mm 595mm 615mm 635mm 655mm
Head Tube Angle 66° 66° 66° 66° 66°
Head Tube Length 100mm 110mm 110mm 130mm 140mm
Seat Tube Angle 74° 74° 74° 74° 74°
Seat Tube Length 15" 16" 17" 18" 20"
Bottom Bracket Height 333mm 333mm 333mm 333mm 333mm
Chainstay Length 426mm 426mm 426mm 426mm 426mm
Wheelbase 1134mm 1156mm 1176mm 1199mm 1220mm
Standover 691mm 715mm 720mm 740mm 790mm
Reach 404mm 422mm 442mm 457mm 474mm
Stack 599mm 608mm 608mm 626mm 635mm
Wheel Size 27.5" (650b)
Frame Material Aluminum
Frame Material Details 6061-T6 Monocoque UK formed custom aluminium tubing
Rear Travel 140mm
Rear Shock FOX Float DPS EVOL Performance, 190mm x 51mm
Optional upgrades: RockShox Monarch DB RT3, FOX Float X EVOL Factory Kashima
Fork FOX 34 Performance, Boost
Optional upgrades: RockShox Pike RCT3 Solo Air Boost, FOX 36 Factory Kashima HSC/LSC Boost
Fork Travel 150mm
Head Tube Diameter Straight
Headset Cane Creek 49mm
Optional upgrade: Hope headset
Handlebar Race Face Chester Riser, 780mm length, 35mm clamp
Stem Race Face Chester, 35mm clamp, 50mm length
Grips Strange lock-on
Brakes Shimano M615, 180mm front rotor, 160mm rear rotor

Optional upgrades: SRAM Guide R, SRAM Ultimate, Hope Tech 3 E4
Brake Levers Shimano M615
Drivetrain 1x
Shifters Shimano SLX, 11-speed
Front Derailleur N/A (1x-specific)
Rear Derailleur Shimano XT Shadow Plus, 11-speed
ISCG Tabs ISCG05
Chainguide Top guide
Optional upgrades: MRP AMG, MRP 1x
Cranks Race Face Aeffect
Chainrings Race Face Aeffect, 30 tooth, direct mount
Bottom Bracket Race Face, 73mm
Optional upgrade: Hope stainless steel
Pedals N/A
Optional upgrades: Hope F20 flat, Burgtec Penthouse MK4 flat
Chain SRAM PC1110, 11-speed
Cassette Shimano SLX, 11-speed, 11-42 tooth
Rims Kore Realm 2.7
Hubs Formula
Spokes
Tires Maxxis High Roller II, EXO TR, 27.5" x 2.3"
Saddle SDG Strange Bel Air 2.0
Seatpost KS Cruxi Integra, 100mm travel
Optional upgrade: RockShox Reverb Stealth
Seatpost Diameter 30.9mm
Seatpost Clamp Strange quick release
Optional upgrades: Hope bolted, Hope quick release
Rear Dropout / Hub Dimensions 148x12mm Boost
Max. Tire Size
Bottle Cage Mounts No
Colors Fizzy Orange, Jet Black
Optional upgrade colors: Cyan Blue, Charcoal Grey, Mountain Mint, Kermit Green, Atomic Orange, Norlando Grey, Blood Red, Minion Yellow
Warranty 3 years frame and Orange components (5 years if registered)
Weight N/A
Miscellaneous UK price: 3,400 British Pounds
Single-pivot suspension
Internal dropper post routing
Price
More Info www.orangebikes.co.uk
