2018 Norco Ryde 26 Bike (discontinued)

Views:
Discontinued
Ryde 26
Create New Tag

Compare to other Bikes

Need more info? View our Dirt Jump / Slopestyle Mountain Bikes buyer's guide.

Specifications

Product Norco Ryde 26 Bike
Model Year 2018
Riding Type Dirt Jump / Slopestyle
Rider Unisex
Sizes and Geometry
Short, Long View Geometry
Size Short Long
Top Tube Length 565mm 580mm
Head Tube Angle 69.5° 69.5°
Head Tube Length 110mm 110mm
Seat Tube Angle 72° 72°
Seat Tube Length 285mm 285mm
Bottom Bracket Height 320mm 320mm
Chainstay Length 383mm 383mm
Wheelbase 1015mm 1030mm
Standover 739mm 732mm
Reach 384mm 399mm
Stack 558mm 558mm
Wheel Size 26"
Frame Material Chromoly
Frame Material Details
Rear Travel Hardtail
Rear Shock N/A
Fork RST Dirt
Fork Travel 100mm
Head Tube Diameter Straight, 1-1/8"
Headset Integrated, FSA
Handlebar Norco 6061, 780mm width, 38mm rise, double butted
Stem Norco alloy 45mm
Grips Norco grip, small flange
Brakes Tektro Aires Mechanical disk brakes, 160mm rotors
Brake Levers Tektro Aires
Drivetrain Other
Shifters N/A
Front Derailleur N/A
Rear Derailleur N/A
ISCG Tabs No
Chainguide N/A
Cranks Three-piece tubular chromo 8 spline
Chainrings Norco 20 tooth, alloy sprocket
Bottom Bracket Sealed 19mm mid, 74mm width
Pedals VP Grind
Chain KMC BMX chain
Cassette 14 tooth freewheel
Rims Alex MUS 30
Hubs Norco alloy, sealed bearings
Spokes Stainless steel 14 gauge, black, 36 count front and rear
Tires Kenda K-Rad 26" x 2.3"
Saddle Norco one piece
Seatpost Integrated
Seatpost Diameter 25.4mm
Seatpost Clamp Integrated
Rear Dropout / Hub Dimensions 10mm x 135mm, nutted
Max. Tire Size
Bottle Cage Mounts No
Colors Splatter red, black
Warranty 3-year limited
Weight N/A
Miscellaneous Rear derailleur hanger integrated into frame
Price $499
More Info

www.norco.com
