2013 Mondraker Factor XR Bike

(discontinued)

Discontinued

Where To Buy
	Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply.	Browse available Bikes
	Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply.	Browse available Bikes

Specifications

Product

Mondraker Factor XR Bike

Model Year

2013

Riding Type

Trail

Rider

Unisex

Sizes and Geometry

Size	M	L
Top Tube Length	25.6	26.6
Head Tube Angle	68°	68°

Seat Tube Angle	74°	74°
Seat Tube Length	16.5	18.5
Bottom Bracket Height	0mm Drop	0mm Drop
Chainstay Length	16.9	16.9
Wheelbase	46.9	47.8

Wheel Size

26"

Frame Material

Aluminum

Frame Material Details

Factor Stealth Alloy Zero Suspension System FG

Rear Travel

120mm

Rear Shock

Fox Float CTD LV BV Factory Kashima 190x50mm

Fork

Fox 32 Talas CTD FIT Factory Kashima

Fork Travel

140-110mm

Head Tube Diameter

1-1/8” to 1.5”

Headset

Onoff Integrated Tapered

Handlebar

Mondraker Factor XR Custom Design 31.8mm x 740mm

Stem

Onoff Stoic FG 10mm

Grips

Onoff Paw Lock-On

Brakes

Formula The One S, 180mm Rotors

Brake Levers

Formula The One S

Drivetrain

Shifters

Shimano XT SL-M786-10

Front Derailleur

Shimano XT FD M-786-10D Direct Mount

Rear Derailleur

Shimano XT RD-M781 SGS 10-Speed

ISCG Tabs

Chainguide

Cranks

Race Face Turbine

Chainrings

38/24 Tooth

Bottom Bracket

Race Face X-Type

Pedals

N/A

Chain

Sram PC-1031 10-Speed

Cassette

Sram PG-1050 12-36 Tooth 10-Speed

Rims

Easton EA 70 XCT Tubeless Wheelset

Hubs

Easton EA70 XCT 15mm Front, Easton EA70 XCT with RockShox Maxle Lite

Spokes

Easton

Tires

Schwalbe Hans Dampf 26"x2.35"

Saddle

Fizik Ardea

Seatpost

CrankBrothers Kronolog Remote

Seatpost Diameter

31.6mm

Seatpost Clamp

Rear Dropout / Hub Dimensions

12x142mm

Max. Tire Size

Bottle Cage Mounts

Yes

Colors

Black

Warranty

Weight

26 lb 10.8 oz (12,100 g)

Miscellaneous

Price

More Info
