2014 Mondraker Factor R Bike (discontinued)

Views:
Discontinued
2014 Mondraker Factor R bike
2014 Mondraker Factor R Bike 2014 Mondraker Factor R Bike
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes buyer's guide.

Specifications

Product Mondraker Factor R Bike
Model Year 2014
Riding Type Trail
Rider Unisex
Sizes and Geometry
S, M, L, XL View Geometry
Size S M L XL
Top Tube Length 595mm 630mm 660mm 690mm
Head Tube Angle 69.5° 69.5° 69.5° 69.5°
Head Tube Length 100mm 100mm 115mm 130mm
Seat Tube Angle 74.5º 74.5º 74.5º 74.5º
Seat Tube Length 395mm 440mm 480mm 520mm
Bottom Bracket Height 340mm 340mm 340mm 340mm
Chainstay Length 445mm 445mm 445mm 445mm
Wheelbase 1140mm 1175mm 1206mm 1238mm
Standover
Reach 433mm 468mm 494mm 520mm
Stack 584mm 584mm 599mm 612mm
Wheel Size 29"
Frame Material Aluminum
Frame Material Details 29" Alloy
Rear Travel 120mm
Rear Shock FOX Float CTD LV Evolution Remote, 190x50mm
Fork FOX 32 Float 29 CTD Remote Evolution, 15mm, Tapered
Fork Travel 120mm
Head Tube Diameter Tapered
Headset Onoff Integrated Tapered 1-1/8"
Handlebar Race Face Evolve, 31.8mm, Flat, 720mm
Stem Onoff Peak FG, 50mm
Grips Onoff Wave
Brakes Formula C1, 180mm Front / 160mm Rear Rotors
Brake Levers Formula C1
Drivetrain 2x
Shifters Shimano SLX SL-M670
Front Derailleur Shimano SLX FD-M671, Direct Mount
Rear Derailleur Shimano XT RD-M781 SGS, 10-Speed
ISCG Tabs
Chainguide N/A
Cranks Shimano XT FC-M785
Chainrings 38/24 Tooth
Bottom Bracket Shimano HollowTech II
Pedals N/A
Chain SRAM PC-1031, 10-Speed
Cassette SRAM PG-1030, 11-36 Tooth, 10-Speed
Rims DT X1900 Spline 29" Wheelset
Hubs DT X1900 Spline 15mm Front // DT X1900 Spline with 12mm DT RWS Axle Rear
Spokes DT
Tires Maxxis Crossmark, 29" x 2.10"
Saddle Mondraker Factor R 29er
Seatpost Race Face Evolve, 375mm
Seatpost Diameter 31.6mm
Seatpost Clamp Quick Release
Rear Dropout / Hub Dimensions 12mm x 142mm
Max. Tire Size
Bottle Cage Mounts Yes
Colors White Grey
Warranty Lifetime Frame // All Components, Suspension Forks and Rear Shock Absorbers are Covered by Manufacturer Original Warranties
Weight 27 lb 16 oz (12,700 g)
Miscellaneous
Price N/A
