2022 Commencal RMNS 14 Bike

Views:
2022 Commencal RMNS 14 (Metallic Purple)
2022 Commencal RMNS 14 Bike 2022 Commencal RMNS 14 Bike 2022 Commencal RMNS 14 Bike
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

Specifications

Product Commencal RMNS 14 Bike
Model Year 2022
Riding Type Cross Country, Trail
Rider Kids
Sizes and Geometry
One Size View Geometry
Size One Size
Top Tube Length 342mm
Head Tube Angle 70°
Head Tube Length 95mm
Seat Tube Angle 73°
Seat Tube Length 175mm
Bottom Bracket Height 0mm drop
Chainstay Length 240mm
Wheelbase 620mm
Standover 400mm
Reach 247mm
Stack 311mm
* Additional Info Recommended for riders roughly 95-110cm tall
Wheel Size Other (14")
Frame Material Aluminum
Frame Material Details 6061 T6 alloy
Rear Travel Hardtail
Rear Shock None
Fork Commencal RMNS, 6061 alloy
Fork Travel None (rigid)
Head Tube Diameter Straight, 1.125"
Headset Neco H-148, semi-integrated
Handlebar RIDE ALPHA, 6061 alloy, 480mm width, 25mm rise, 25.4mm clamp diameter, tapered for 19mm grips
Stem Commencal Alloy, 30mm length, 25.4mm bar clamp
Grips Commencal Kids, for 19mm handlebar diameter
Brakes Tektro Aries, 2-piston mechanical disc, Tektro 160mm 6-bolt rotors
Brake Levers Tektro Aries, kids-specific
Drivetrain 1x
Shifters None
Front Derailleur None
Rear Derailleur None
ISCG Tabs None
Chainguide None
Cranks Commencal Kids, 89mm length
Chainrings 28 tooth, with cover
Bottom Bracket Neco B-910, ball retainer, 68mm English/BSA threaded
Pedals Platform
Chain C-410 singlespeed, 1/2" x 1/8"
Cassette Single 18 tooth cog
Rims Commencal, 6063 alloy, 20 hole
Hubs Commencal, loose ball bearings
Spokes 2.0mm
Tires VEE Tire Co. Crown Gem, MPC compound, custom "Send It" patch, 14" x 2.25"
Saddle Commencal Kids, soft padding
Seatpost Commencal Alloy
Seatpost Diameter 27.2mm
Seatpost Clamp Single bolt, 31.8mm
Rear Dropout / Hub Dimensions 3/8" x 115mm
Max. Tire Size
Bottle Cage Mounts None
Colors Silver, Keswick Green, Metallic Purple
Warranty 5 years frame and Commencal/RIDE ALPHA components; 6 months paint/decals
Weight 16 lb 12.1 oz (7,600 g)
Miscellaneous • External cable routing
• Includes bell and lights
• Recommended for riders roughly 95-110cm tall
Price
More Info Commencal Updates the RMNS (Ramones) Kids Range (press release)
