2020 Cannondale Trail 2 Bike

Views:
2020 Cannondale Trail 2
2020 Cannondale Trail 2 Bike 2020 Cannondale Trail 2 Bike 2020 Cannondale Trail 2 Bike 2020 Cannondale Trail 2 Bike 2020 Cannondale Trail 2 Bike
Related: Cannondale
Cannondale
Edit Tags Done
Create New Tag
Edit Tags Done

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

Specifications
Product Cannondale Trail 2 Bike
Model Year 2020
Riding Type Cross Country, Trail
Rider Unisex
Sizes and Geometry
XS, SM, MD, LG, XL, 2XL View Geometry
Size XS SM MD LG XL 2XL
Top Tube Length 545mm 585mm 610mm 635mm 660mm 685mm
Head Tube Angle 68.0° 68.0° 68.5° 68.5° 68.5° 68.5°
Head Tube Length 95mm 105mm 115mm 125mm 135mm 145mm
Seat Tube Angle 73.5° 73.5° 73.5° 73.5° 73.5° 73.5°
Seat Tube Length 345mm 400mm 440mm 480mm 520mm 560mm
Bottom Bracket Height 304mm (60mm drop) 304mm (60mm drop) 308mm (65mm drop) 308mm (65mm drop) 308mm (65mm drop) 308mm (65mm drop)
Chainstay Length 440mm 440mm 445mm 445mm 445mm 445mm
Wheelbase 1067mm 1108mm 1140mm 1166mm 1192mm 1218mm
Standover 710mm 746mm 795mm 820mm 850mm 880mm
Reach 365mm 402mm 425mm 447mm 470mm 492mm
Stack 607mm 616mm 624mm 633mm 643mm 652mm
* Additional Info XS/SM have 27.5" wheels; MD/LG/XL/2XL have 29" wheels.
Wheel Size 27.5" (650b), 29"
Frame Material Aluminum
Frame Material Details SmartForm C2 alloy, SAVE flex zones
Rear Travel Hardtail
Rear Shock N/A
Fork RockShox Judy Gold RL, Solo Air spring, Fast Black uppers, 42mm offset (27.5"), 51mm offset (29")
Fork Travel 120mm
Head Tube Diameter Tapered, 1.125" top, 1.5" bottom
Headset Semi-integrated
Handlebar Cannondale 3 Riser, 6061 alloy, 8° backsweep, 4° upsweep, 760mm width, 15mm rise, 31.8mm clamp diameter
Stem Cannondale 3, alloy, 31.8mm bar clamp, with SP-Connect Intellimount
Grips Cannondale lock-on
Brakes Shimano MT400, hydraulic, Shimano RT30 rotors (180mm front, 160mm rear)
Brake Levers Shimano MT400
Drivetrain 1x
Shifters SRAM SX Eagle, 12-speed
Front Derailleur N/A
Rear Derailleur SRAM SX Eagle, 12-speed
ISCG Tabs No
Chainguide N/A
Cranks SRAM SX Eagle PowerSpline
Chainrings SRAM SX Eagle, 30 tooth
Bottom Bracket Truvativ PowerSpline, 73mm BSA threaded
Pedals Cannondale Platform
Chain SRAM SX Eagle, 12-speed
Cassette SRAM SX Eagle PG1210, 11-50 tooth, 12-speed
Rims WTB STX i23 TCS, 32 hole, tubeless ready, 27.5" (XS/SM), 29" (MD/LG/XL/2XL)
Hubs Shimano MT400, 32 hole, 110x15mm Boost front, 141x9mm rear with HG driver
Spokes Stainless steel, 14g
Tires WTB Breakout Comp, DNA compound, 2.3"
Saddle Cannondale Stage 3
Seatpost TranzX dropper, internal routing, 80mm drop (XS), 100mm drop (SM), 120mm drop (MD/LG/XL/2XL)
Seatpost Diameter 31.6mm
Seatpost Clamp Quick release
Rear Dropout / Hub Dimensions 141x9mm
Max. Tire Size
Bottle Cage Mounts Yes (double)
Colors Acid Red
Warranty Lifetime frame; 1 year paint, decals, and Cannondale components
Weight 31 lb 14.4 oz (14,470 g)
Miscellaneous Straight Shot internal routing for shift/dropper post cables; external brake line routing
Weight given for size MD
XS/SM have 27.5" wheels; MD/LG/XL/2XL have 29" wheels
Integrated wheel sensor at front hub helps track activity via Cannondale app
Price $1,600
More Info

cannondale.com
