2021 Trek Roscoe 6 Bike

Views:
2021 Trek Roscoe 6 (Lithium Grey/Cobra Blood)
2021 Trek Roscoe 6 Bike 2021 Trek Roscoe 6 Bike 2021 Trek Roscoe 6 Bike 2021 Trek Roscoe 6 Bike
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

Specifications

Product Trek Roscoe 6 Bike
Model Year 2021
Riding Type Cross Country, Trail
Rider Unisex
Sizes and Geometry
XS, SM, MD, ML, LG, XL View Geometry
Size XS SM MD ML LG XL
Top Tube Length 558mm 574mm 609mm 625mm 645mm 666mm
Head Tube Angle 67.1° 67.2° 67.2° 67.3° 67.3° 67.4°
Head Tube Length 90mm 90mm 90mm 90mm 100mm 120mm
Seat Tube Angle 69.7° 70.2° 69.6° 69.6° 69.7° 69.7°
Seat Tube Length 343mm 368mm 419mm 444mm 470mm 521mm
Bottom Bracket Height 310mm (50mm drop) 320mm (40mm drop) 319mm (41mm drop) 319mm (41mm drop) 319mm (41mm drop) 318mm (42mm drop)
Chainstay Length 438mm 438mm 438mm 438mm 438mm 438mm
Wheelbase 1059mm 1081mm 1110mm 1126mm 1146mm 1168mm
Standover 731mm 754mm 751mm 748mm 763mm 760mm
Reach 351mm 364mm 394mm 410mm 428mm 442mm
Stack 605mm 614mm 614mm 615mm 625mm 644mm
Wheel Size 27.5+
Frame Material Aluminum
Frame Material Details Alpha Gold Aluminum
Rear Travel Hardtail
Rear Shock N/A
Fork SR Suntour XCM 32, coil spring, preload adjust, lockout, 47mm offset
Fork Travel XS: 100mm
SM/MD/ML/LG/XL: 120mm
Head Tube Diameter Tapered, 1.125" top, 1.5" bottom
Headset Semi-integrated, cartridge bearing
Handlebar Bontrager alloy, 31.8mm clamp diameter, 15mm rise
Width: 720mm (XS), 750mm (SM/MD/ML/LG/XL)
Stem Bontrager alloy, 31.8mm bar clamp, Blendr compatible, 7° rise
Length: 50mm (XS/SM/MD), 60mm (ML/LG/XL)
Grips Bontrager XR Trail Comp, nylon lock-on
Brakes Shimano MT200, 2-piston, Shimano RT26 6-bolt rotors (160mm front [XS/SM], 180mm front [MD/ML/LG/XL/XXL], 160mm rear)
Brake Levers Shimano MT200
Drivetrain 1x
Shifters Shimano Deore M4100, 10-speed
Front Derailleur None
Rear Derailleur Shimano Deore M5120, 10-speed, long cage
ISCG Tabs None
Chainguide None
Cranks FSA Alpha Drive
Length: 170mm (XS/SM), 175mm (MD/ML/LG/XL)
Chainrings FSA Alpha Drive, 28 tooth, steel
Bottom Bracket Shimano 7420ST, 73mm BSA threaded
Pedals VP-536 nylon platform
Chain KMC X10, 10-speed
Cassette Shimano Deore M4100, 10-speed, 11-46 tooth
Rims Alexrims MD35, tubeless ready, 32 hole
Hubs Front: Formula DC-511, 6-bolt rotor mount, 32 hole, 110x15mm Boost
Rear: Formula DC-2241, 6-bolt rotor mount, 32 hole, Boost141 axle, HG driver
Spokes 14g, stainless steel
Tires Schwalbe Rocket Ron, Performance, wire bead, 27.5" x 2.8"
Saddle Bontrager Arvada, steel rails, 138mm width
Seatpost TranzX JD-YSP18 dropper
Drop: 100mm (XS/SM/MD), 130mm (ML/LG/XL/XXL)
Seatpost Diameter 31.6mm
Seatpost Clamp Single bolt
Rear Dropout / Hub Dimensions Boost141 quick release
Max. Tire Size 27.5" x 2.8" or 29" x 2.4"
Bottle Cage Mounts Two inside front triangle
Colors Lithium Grey/Cobra Blood, Purple Flip/Trek Black
Warranty Lifetime frame and wheels; 2 years Trek/Bontrager parts and paint/decals
Weight 34 lb 13.7 oz (15,810 g)
Miscellaneous Compatible with 29" wheels
Internal cable routing
Weight given for MD frame with tubes
Includes rack and kickstand mounts
Price $1,049.99
More Info trekbikes.com
