2023 Trek Fuel EX 9.9 XTR Gen 6 Bike

AvgAverage User Rating
Related:
Where To Buy
Free standard shipping on all bikes (continental U.S. only).
Flat rate shipping to Hawaii and Alaska.
Free standard shipping on all bikes (continental U.S. only).
Flat rate shipping to Hawaii and Alaska.
$8,749.99
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.

1 member reviews

Fuel EX
Rating:
The Good
Many size options. Medium fit perfect in the saddle with shorter 580’ish ETT for me at just under 5’7”, while still having between 455-460 reach depending on flip chip and headset positions. Climbs excellent with minimal bob. Snappy but still plush enough over slow tech stuff to not be jarring. Shines on the downs with feel of more travel (140/160). Storage area and bag are perfect size for pump, plug kit and multi-tool.
The Bad
Only complaint is slight rattle when riding chunky terrain coming from the forward section of the down tube due to the plastic internal cable guide tubes. They’re not affixed/molded to the carbon frame like other manufacturer frames. Gonna try motofoam to fix with easy access with the storage compartment.
Overall Review:

Great Trail bike (or enduro bike in the right hands) with tons of adjustment for the perfect fit as well as sizes to fit just about any rider out there.

0 comments

Post a reply to: Fuel EX

Specifications

Product
Trek Fuel EX 9.9 XTR Gen 6 Bike
Model Year
2023
Riding Type
Trail
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
XS 27.5"
SM 27.5"
SM 29"
MD 29"
ML 29"
LG 29"
XL 29"
XXL 29"
Wheel Size
27.5" (650b)
29"
Frame Material
Carbon Fiber
Frame Material Details
OCLV Mountain Carbon front and rear triangles, magnesium rocker link; molded chainstay, lower down tube, and shuttle guard protection
Rear Travel
140mm
Rear Shock
FOX FLOAT X Factory, EVOL, 2-position lever, Kashima coating, 185mm length x 55mm stroke
Fork
FOX FLOAT 36 Factory, EVOL, GRIP2 damper, Kashima coating, 44mm offset, Kabolt thru-axle
Fork Travel
150mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Integrated, cartridge bearings, compatible with optional angle-adjust headset cups
Handlebar
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 820mm width, 27.5mm rise
Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0° rise
Virtual length: 35mm (XS/SM), 45mm (MD-XXL)
Grips
Bontrager XR Trail Elite, nylon lock-on
Brakes
Shimano XTR M9120, 4-piston, Shimano RT86 6-bolt rotors (203mm front, 180mm rear)
Brake Levers
Shimano XTR M9100
Drivetrain
1x
Shifters
Shimano XTR M9100, 12-speed
Front Derailleur
None
Rear Derailleur
Shimano XTR M9100, 12-speed, long cage, SHADOW RD+
ISCG Tabs
ISCG05
Chainguide
None
Cranks
e*thirteen TRS Race Carbon, 170mm length
Chainrings
e*thirteen TRS Race, 30 tooth
Bottom Bracket
e*thirteen BB20-P, 73mm English/BSA threaded
Pedals
None
Chain
Shimano XTR M9100, 12-speed
Cassette
Shimano XTR M9100, 12-speed, 10-51 tooth
Rims
Bontrager Line Pro 30, OCLV Mountain Carbon, tubeless ready
Hubs
Bontrager Line Pro wheelset, 110x15mm Boost front, 148x12mm Boost rear with Rapid Drive 108 freehub and MICRO SPLINE driver
Spokes
Bontrager Line Pro wheelset
Tires
Bontrager SE5 Team Issue, Core Strength casing, aramid bead, 120 TPI, tubeless ready, 2.5"
Saddle
Bontrager Arvada Pro, carbon rails, 138mm width
Seatpost
Bontrager Line Elite dropper, MaxFlow
Drop: 100mm (XS/SM), 150mm (MD/ML), 170mm (LG), 200mm (XL/XXL)
Seatpost Diameter
34.9mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size
2.5"
Bottle Cage Mounts
One inside front triangle
Colors
Deep Smoke, Mulsanne Blue
Warranty
Lifetime frame and rims; 2 years Trek/Bontrager parts, suspension linkage components, and paint/decals
Weight
30 lb 3.3 oz (13,700 g)
Miscellaneous
• ABP (Active Braking Pivot) rear suspension design
• XS has 27.5" wheels, SM available with 27.5" or 29" wheels, MD-XXL have 29" wheels
• 29" versions compatible with mixed ("Mullet") wheel setups (29" front, 27.5" rear)
• Geometry adjustable via Mino Link flip chip in rear rocker link pivot
• Geometry adjustable via optional angle-adjust headset cups, for +1° and -1° head tube angle adjustments
• Internal frame storage compartment in down tube; includes Bontrager BITS storage bag
• Guided internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Includes Bontrager TLR tubeless rim strips, valve stems, and sealant
• Weight given for size MD set up tubeless

Rear suspension leverage rate adjustable via flip chip at lower shock mount:
• Less progressive setting intended for a plusher feel perfect for rugged trails with square-edge bumps
• More progressive setting intended for hitting big features without bottom-out, or to run a coil shock
Price
$9,749.99
