Specifications

Product

Spawn Kotori 26" Bike

Model Year

2021

Riding Type

Dirt Jump / Slopestyle

Rider

Kids

Unisex

Sizes and Geometry

One Size

Size	One Size
Top Tube Length	590mm
Head Tube Angle	68.5°
Head Tube Length	125mm

Seat Tube Length	320mm

Chainstay Length	395mm
Wheelbase	1055mm



Additional Info	Intended for riders roughly 11+ years old, 56"+ tall, with 26-32" inseam

Wheel Size

26"

Frame Material

Aluminum

Frame Material Details

6061-T6 alloy, hydroformed down tube

Rear Travel

Hardtail

Rear Shock

None

Fork

RockShox Reba, rebound adjust

Fork Travel

100mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Sealed bearings, semi-integrated

Handlebar

Brood Bike Co. A Bar Named Sue

Stem

Spawn, alloy, 40mm length

Grips

Brood Bike Co. Tenderiderz

Brakes

Tektro Auriga, 2-piston, rear only

Brake Levers

Tektro Auriga, rear only

Drivetrain

Shifters

None

Front Derailleur

None

Rear Derailleur

None

ISCG Tabs

ISCG05

Chainguide

None

Cranks

Brood Bike Co. Styx, 2-piece alloy

Chainrings

Brood Bike Co., direct mount, 32 tooth

Bottom Bracket

External, sealed cartridge bearings

Pedals

Wellgo alloy platform

Chain

KMC K810

Cassette

Single cog, 14 tooth

Rims

Alloy, 32 hole

Hubs

Alloy, sealed bearings, 100x15mm quick release front, 135x10mm bolt-on rear

Spokes

Tires

Kenda Small Block Eight, 26" x 2.1"

Saddle

Brood Bike Co. Throne pivotal

Seatpost

Alloy pivotal

Seatpost Diameter

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

135x10mm, sliding, for bolt-on axles

Max. Tire Size

Bottle Cage Mounts

One inside front triangle

Colors

Neon Green, Cosmic Grape, Black

Warranty

Weight

Miscellaneous

• External cable routing
• Intended for riders roughly 11+ years old, 56"+ tall, with 26-32" inseam

Price

$1,525.00
