2022 Knolly Chilcotin 167 XT Bike

Views:
2022 Knolly Chilcotin 167 (Raw, GX build shown)
2022 Knolly Chilcotin 167 XT Bike 2022 Knolly Chilcotin 167 XT Bike
Create New Tag

Compare to other Bikes

Specifications

Product Knolly Chilcotin 167 XT Bike
Model Year 2022
Riding Type Enduro / All-Mountain, Freeride / Bike Park
Rider Unisex
Sizes and Geometry
MD (Neutral, Slack), LG (Neutral, Slack), XL (Neutral, Slack) View Geometry
Size MD (Neutral, Slack) LG (Neutral, Slack) XL (Neutral, Slack)
Top Tube Length 632mm 660mm 688mm
Head Tube Angle 64.5°, 63.8° 64.5°, 63.8° 64.5°, 63.8°
Head Tube Length 98mm 106mm 110mm
Seat Tube Angle 77.6°, 76.9° 77.6°, 76.9° 77.6°, 76.9°
Seat Tube Length 405mm 456mm 503mm
Bottom Bracket Height 347mm, 338mm 347mm, 338mm 347mm, 338mm
Chainstay Length 436.5mm, 438.0mm 436.5mm, 438.0mm 436.5mm, 438.0mm
Wheelbase 1234mm 1263mm 1291mm
Standover 710mm 750mm 790mm
Reach 464mm 490mm 516mm
Stack 626mm 633mm 637mm
* Additional Info Geometry adjustable via dual settings at lower shock mount
Wheel Size 29"
Frame Material Aluminum
Frame Material Details 6066 aluminum, custom titanium hardware, molded chainstay and down tube protection
Rear Travel 167mm
Rear Shock FOX FLOAT X2 Factory
Fork FOX FLOAT 38 Performance Elite, GRIP2 damper, 44mm offset
Fork Travel 170mm
Head Tube Diameter Tapered, 1.125" top, 1.5" bottom
Headset Cane Creek 40 Series, ZS44 upper, ZS56 lower
Handlebar Race Face Next R, 800mm width, 20mm rise, 35mm clamp diameter
Stem Race Face Aeffect R, 40mm length, 35mm bar clamp
Grips Chromag Basis
Brakes Shimano Deore XT M8120, 4-piston, Shimano Deore XT RT76 6-bolt rotors (203mm front, 180mm rear)
Brake Levers Shimano Deore XT M8120
Drivetrain 1x
Shifters Shimano Deore XT M8100, 12-speed, I-SPEC EV bracket
Front Derailleur None
Rear Derailleur Shimano Deore XT M8100, 12-speed, SHADOW RD+
ISCG Tabs ISCG05, removable
Chainguide None
Cranks Shimano Deore XT M8130, 170mm length
Chainrings Shimano Deore XT M8130, 30 tooth
Bottom Bracket Shimano Deore XT MT800, 73mm English/BSA threaded
Pedals None
Chain Shimano Deore XT M8100, 12-speed
Cassette Shimano Deore XT M8100, 12-speed, 10-51 tooth, HYPERGLIDE+
Rims Industry Nine Enduro S, 28 hole
Hubs Industry Nine Hydra, 110x15mm Boost front, 157x12mm SuperBoost rear with MICRO SPLINE driver
Spokes Industry Nine Enduro S wheelset, straight-pull
Tires Front: Maxxis Assegai, 3C MaxxGrip, EXO+, 29" x 2.5" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra, Double Down (DD), 29" x 2.4"
Saddle Chromag Lynx DT
Seatpost FOX Transfer Performance Elite dropper, FOX 1x remote lever
Seatpost Diameter 31.6mm
Seatpost Clamp Knolly single bolt, 35.0mm
Rear Dropout / Hub Dimensions 157x12mm SuperBoost
Max. Tire Size 29" x 2.6"
Bottle Cage Mounts One inside front triangle
Colors Raw, Blue
Warranty Lifetime frame
Weight
Miscellaneous • Fourby4 suspension system
• Geometry adjustable via dual settings at lower shock mount (Neutral or Slack settings)
• Internal cable routing with Di2 battery compartment
• Photos show GX build
Price $6,799.99
More Info knollybikes.com
