2021 Guerrilla Gravity The Smash Ride Bike

Views:
2021 Guerrilla Gravity The Smash (Metallic Silver decals, Race build shown)
2021 Guerrilla Gravity The Smash Ride Bike 2021 Guerrilla Gravity The Smash Ride Bike 2021 Guerrilla Gravity The Smash Ride Bike 2021 Guerrilla Gravity The Smash Ride Bike 2021 Guerrilla Gravity The Smash Ride Bike 2021 Guerrilla Gravity The Smash Ride Bike 2021 Guerrilla Gravity The Smash Ride Bike
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes or Enduro / All-Mountain Mountain Bikes buyer's guides.

Specifications

Product Guerrilla Gravity The Smash Ride Bike
Model Year 2021
Riding Type Trail, Enduro / All-Mountain
Rider Unisex
Sizes and Geometry
2 (Short, Long), 3 (Short, Long), 4 (Short, Long) View Geometry
Size 2 (Short, Long) 3 (Short, Long) 4 (Short, Long)
Top Tube Length 586mm, 596mm 615mm, 625mm 652mm, 662mm
Head Tube Angle 64.7° 64.7° 64.7°
Head Tube Length 100mm 120mm 140mm
Seat Tube Angle 77.1° 77.0° 76.8°
Seat Tube Length 400mm 430mm 480mm
Bottom Bracket Height 344mm 344mm 344mm
Chainstay Length 440mm 440mm 440mm
Wheelbase 1211mm, 1221mm 1244mm, 1254mm 1283mm, 1293mm
Standover 730mm 731mm 737mm
Reach 446mm, 456mm 471mm, 481mm 500mm, 510mm
Stack 610mm 628mm 646mm
* Additional Info All specifications listed are with 150mm travel fork.
Length adjustable via GeoAdjust headset orientation.
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details Revved Carbon Technology front triangle, 6061 aluminum rear triangle
Rear Travel 145mm
Rear Shock RockShox Deluxe Select, 230mm x 60mm
Options: RockShox Deluxe Select+, RockShox Super Deluxe Select+
Fork RockShox Lyrik Select
Options: RockShox Lyrik Select+, DVO Diamond D2
Fork Travel 150mm
Head Tube Diameter Tapered, 1.125" top, 1.5" bottom
Headset Guerrilla Gravity GeoAdjust
Handlebar e*thirteen Base, 800mm width, 20mm rise, 35mm clamp diameter
Option: Race Face Next R, 780mm width, 20mm rise, 35mm clamp diameter
Stem e*thirteen Base, 40mm or 50mm length, 35mm bar clamp
Option: Race Face Aeffect R, 60mm length, 35mm bar clamp
Grips ODI Elite Pro, lock-on
Brakes SRAM Guide T, 4-piston, SRAM CenterLine rotors
Options: SRAM G2 R, 4-piston, SRAM CenterLine rotors; SRAM G2 RSC, 4-piston, SRAM CenterLine rotors; SRAM Code R, 4-piston, SRAM CenterLine rotors; Shimano Deore XT M8120, 4-piston, Shimano RT86 rotors
Brake Levers SRAM Guide T
Drivetrain 1x
Shifters Box Two Prime 9, 9-speed
Drivetrain options: SRAM GX Eagle, 12-speed; SRAM NX Eagle, 12-speed
Front Derailleur None
Rear Derailleur Box Two Prime 9, 9-speed
Drivetrain options: SRAM GX Eagle, 12-speed; SRAM NX Eagle, 12-speed
ISCG Tabs ISCG05
Chainguide None
Options: MRP 1x, MRP XCG, MRP AMg Alloy, MRP AMg Carbon
Cranks Rotor Kapic
Options: Truvativ Descendant 6K Eagle (with SRAM NX Eagle drivetrain), Truvativ Descendant Eagle Carbon (with SRAM GX Eagle drivetrain)
Chainrings Rotor Kapic
Option: Truvativ Descendant Eagle (with SRAM drivetrains)
Bottom Bracket 73mm English/BSA threaded
Pedals None
Chain Box Two Prime 9, 9-speed
Drivetrain options: SRAM GX Eagle, 12-speed; SRAM NX Eagle, 12-speed
Cassette Box Two Prime 9, 9-speed, 11-50 tooth
Drivetrain options: SRAM NX Eagle PG-1230, 12-speed, 11-50 tooth; SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth
Rims SUNringlé Duroc SD37 Comp wheelset
Option: DT Swiss M1900 i30 wheelset
Hubs SUNringlé Duroc SD37 Comp wheelset, 110x15mm Boost front, 148x12mm Boost rear
Option: DT Swiss M1900 i30 wheelset
Spokes SUNringlé Duroc SD37 Comp wheelset
Option: DT Swiss M1900 i30 wheelset
Tires Front: Maxxis Minion DHF, 3C, EXO, TR, 29" x 2.5"
Rear: Maxxis Minion DHR II, 3C, EXO, TR, 29" x 2.3"
Front options: Maxxis Minion DHF (2.3"), Maxxis Assegai (2.5")
Rear options: Maxxis Dissector (2.4"), Maxxis Aggressor (2.3" or 2.5")
Saddle SDG Radar, Guerrilla Gravity Custom
Seatpost SDG Tellis dropper, 150mm or 170mm drop
Seatpost Diameter 30.9mm
Seatpost Clamp Single bolt, 37mm
Rear Dropout / Hub Dimensions 148x12mm Boost
Max. Tire Size 29" x 2.5"
Bottle Cage Mounts One inside front triangle, plus accessory mounts on down tube
Colors Grey
Decal color options: Metallic Silver, Black, Metallic Purple, Metallic Blue, Metallic Red, Orange
Warranty Lifetime frame support with discounted replacement
Weight 33 lb 12.8 oz (15,331 g)
Miscellaneous • Freedom Linkage suspension design
• Integrated-External cable routing
• Modular Frame Platform and Seatstay Tuning Kits allows conversion of bike from one model to another
• Weight given for size 2 frame
• Photos show Race build

Flip chip in rear shock mount provides Crush and Plush modes:
• Crush Mode: strong mid-stroke support for flow trails and all-day adventures
• Plush Mode: softer top stroke for smashing rocks and mega-traction
Price $4,195
More Info ridegg.com
