2021 Devinci Troy Carbon XT LTD Bike

Views:
2021 Devinci Troy Carbon XT LTD (Purple Ghost)
2021 Devinci Troy Carbon XT LTD Bike 2021 Devinci Troy Carbon XT LTD Bike
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes or Enduro / All-Mountain Mountain Bikes buyer's guides.

The New Devinci Troy Just Arrived (Literally!)

The 2021 Devinci Troy receives a slew of updates but stays true to its roots

The New Devinci Troy Just Arrived (Literally!)

Spotted last week beneath EWS racer, Greg Callahan, and teased on the Devinici site, the new Troy has been officially launched. Devinci touts the revised 29er as a quiver killer, a bike capable of tackling all types of terrain for every type of rider. Our test bike was delayed in customs and showed up only hours ago, so we can't speak as to whether the new Troy lives up to the claims. Vital is happy to have one in the house and a we look forward to giving this bike a proper rundown.

Highlights

  • 140mm travel frame
  • 150mm and 160mm travel fork options
  • 29-inch wheels only
  • Super Boost rear hub spacing
  • Carbon and alloy frame options
  • Coil shock compatible
  • Lifetime frame warranty
  • Internal cable routing
  • Trunnion rear shock
  • Flip chip at lower shock mount
  • Size-specific chainstay lengths


Internal routing and tidy upon exit
Flip chip

A host of revisions and refinements, much like we saw in last year's Django update, make the new Troy more capable in rowdy terrain while not seeming to take things too far into the enduro realm. When lining the Troy up next to the 2020 model, all of the usual suspects are there. The new Troy has a longer reach, slacker head angle, steeper seat angle, and longer chainstays across all sizes. Beyond basic number changes, the 2021 Troy features a number of refinements including increased tire clearance and a narrower rear end, though it keeps the Super Boost spacing. Absent from the 2021 line is a 27.5-inch wheeled option, the new Troy is 29er only.

The new Troy will easily clear a 29x2.6-inch wide tire

Trunnion shock on all models
Double-row linkage bearings

Geometry

2021 Devinci Troy Geometry - 150mm fork. 160mm fork will slacken the head angle by .5-degrees, cause a slight raise in BB height, and have a small effect on the seat angle.

With the flip chip located on the lower shock mount, riders can adjust the head angle by .5-degrees (65/65.5), this also slackens the seat angle by .5-degrees, which varies for each size. For 2021 the Troy incorporates three different chainstay lengths for various sizes. Small and medium frames share a 435/433mm stay, large is 440/438mm, and the x-large sits at 445/443mm.

Frame protection
Three sizes fit most - size specific chainstays



While there is only one wheel size, there is still the option of carbon or aluminum frames in a variety of trims. The particular build that showed up for Vital is the Carbon XT 12s LTD. The LTD moniker delivers an extra 10mm of travel to the FOX 36 Performance Elite fork and bumps the Maxxis Minions to MaxxGrip Double Down casing where the rest of the Troy line has MaxTerra EXO+.


2021 Devinci Troy Line

Carbon XT 12s LTD - $6,199 USD
Carbon GX 12s - $5,199 USD

Troy Carbon/Alloy GX 12s - $4,399 USD

  • Carbon front triangle, alloy rear
  • Shock: FOX DPX2 Performance Elite
  • Fork: FOX Float 36 Performance
  • Rims: Race Face AR35
  • Tires: Maxxis Minion DHF/DHR 29x2.5/2.4WT EXO+
  • Drivetrain: SRAM GX Eagle
  • Brakes: SRAM Code R
  • Seatpost: SDG Tellis
GX 12s Alloy - $3,599 USD
Deore 12s Alloy - $2,799 USD

Want to see all five models of the new Troy side-by-side? Here you go, courtesy of our Product Guide. For a look at the complete Troy line in various color options, head to Devinci.com



Specifications

Product Devinci Troy Carbon XT LTD Bike
Model Year 2021
Riding Type Trail, Enduro / All-Mountain
Rider Unisex
Sizes and Geometry
S (Lo, Hi), M (Lo, Hi), L (Lo, Hi) , XL (Lo, Hi) View Geometry
Size S (Lo, Hi) M (Lo, Hi) L (Lo, Hi) XL (Lo, Hi)
Top Tube Length 574, 573 598, 597 626, 625 655, 654
Head Tube Angle 64.5°, 65.0° 64.5°, 65.0° 64.5°, 65.0° 64.5°, 65.0°
Head Tube Length 95 105 115 125
Seat Tube Angle 77.6°, 78.1° 77.5°, 78.0° 76.9°, 77.4° 76.4°, 76.9°
Seat Tube Length 400 420 445 495
Bottom Bracket Height 344, 351 344, 351 344, 351 344, 351
Chainstay Length 435, 433 435, 433 440, 438 445, 443
Wheelbase 1190, 1189 1215, 1213 1244, 1243 1273, 1272
Standover 733, 738 754, 759 769, 775 780, 786
Reach 440, 445 460, 465 480, 485 500, 505
Stack 612, 608 621, 617 631, 626 640, 635
* Additional Info Geometry with a 160mm fork; measurements in mm unless otherwise noted
Adjustable geometry between Hi/Lo positions via a flip chip in the lower shock mount
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details Full cabon DMC-G with hidden pivots, internal routing, and integrated frame guards
Rear Travel 140mm
Rear Shock FOX FLOAT X2 Performance Elite, trunnion, 185x52.5mm, 0.3 volume spacer
Fork FOX FLOAT 36 Performance Elite, GRIP2, 44mm offset
Fork Travel 160mm
Head Tube Diameter Tapered
Headset FSA Orbit 1.5 Zero Stack
Handlebar Race Face Next R 35, 20mm rise, 800mm width
Stem Race Face Turbine R 35, 50mm length, 0° rise
Grips Devinci Performance, lock-on
Brakes Shimano XT M8120/M8100, 4-piston, with Shimano RT76 203mm rotors
Brake Levers Shimano XT M8120/M8100
Drivetrain 1x
Shifters Shimano XT M8100, I-SPEC EV, 12-speed
Front Derailleur NA
Rear Derailleur Shimano XT M8100, 12-speed
ISCG Tabs 2-bolt ISCG 05
Chainguide e*thirteen TRS Race SL Carbon
Cranks Shimano XT M8130-1, Super Boost
Chainrings 32 tooth
Bottom Bracket Shimano MT800, BSA 68/73mm threaded
Pedals N/A
Chain Shimano M7100, 12-speed
Cassette Shimano M8100, 12-speed, 10-51 tooth
Rims Race Face ARC 35, 29", 35mm inner width, tubeless ready
Hubs Front: Race Face Vault, 6-bolt, TA 15mm x 110mm
Rear: Race Face Vault, 6-bolt, TA 12mm x 157mm Super Boost, Micro Spline driver
Spokes Sapim Stainless 14G with Nylok
Tires Front: Maxxis Minion DHF, 29"x2.5" WT/3C/MaxxGrip/DoubleDown/TR
Rear: Maxxis Minion DHR II, 29"x2.4" WT/3C/MaxxGrip/DoubleDown/TR
Saddle SDG Belair 3.0
Seatpost SDG Tellis with SDG Tellis I-SPEC EV 1x lever
Seatpost Diameter 34.9mm
Seatpost Clamp Alloy CNC single-bolt, 39.3mm
Rear Dropout / Hub Dimensions 157mm x 12mm (Super Boost)
Max. Tire Size 29"x2.6"
Bottle Cage Mounts Yes (fits a standard 500mL bottle with a piggyback shock)
Colors Gloss Full Sand
Matte Purple Ghost
Warranty Lifetime frame
Weight 32 lb 13.9 oz (14,910 g)
Miscellaneous
  • 4th generation Troy
  • Adaptable chainstay lengths on L/XL bikes for a balanced feel
  • Rider-size appropriate front triangle enhances overall stability and handling (435mm on XS-M, 440mm on L, and 445mm on XL)
  • Cable holder doubles as a lower shock washer for ultra-easy reassembly
  • Rear pivot brake cable clip keeps the cable from rubbing
  • Double-row, double-lip sealed linkage bearings for precision movement and longevity
  • Geometry adjustable between Hi/Lo using the lower shock mount flip chip
  • High-density rock guard and chainstay protector
  • New hardware makes the rear-end 9.5mm slimmer, improving clearance
  • Seatpost compatibility/insertion length: 150/240mm (S), 175/250mm (M), 200/280mm (L-XL)
  • Split pivot rear triangle
  • Metric shock with trunnion mount, coil compatible
  • Price $6,199
