2010 Yeti AS-R Carbon Bike (discontinued)

Discontinued
2010 Yeti AS-R Carbon Bike yeti-asr-carbon
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

    Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

    Vital MTB Retail Partners:
    Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

    Specifications

    Model Year 2010
    Riding Type Cross Country, Trail
    Sizes and Geometry

    S, M, L View Geometry

    Size S M L
    Top Tube Length 22.6 23.6 24.6
    Head Tube Angle 68 68 68
    Head Tube Length 4 4.5 5.3
    Seat Tube Angle 72 72 72
    Seat Tube Length 27.6 28.3 30.7
    Bottom Bracket Height 13 13 13
    Chainstay Length 16.9 16.9 16.9
    Wheelbase 42.8 43.8 44.9
    Standover 27.8 27.8 28.1
    Reach
    Stack
    Frame Material Carbon
    Rear Travel 98mm
    Rear Shock Fox RP23 (6.5x1.5)
    Fork Fox F100 RLC FIT 15mm
    Fork Travel 100
    Head Tube Diameter 1 1/8-inch
    Headset Cane Creek S3
    Handlebar Easton MonkeyLite
    Stem Thomson X4
    Grips Yeti Lock-on
    Brakes Shimano XT 160mm rotors
    Brake Levers Shimano XT
    Shifters Shimano XT
    Front Derailleur Shimano XT
    Rear Derailleur Shimano XTR SGS Shadow
    ISCG Tabs No
    Chainguide N/A
    Cranks Shimano XT
    Chainrings 22/32/42
    Bottom Bracket Shimano
    Pedals
    Chain Shimano, 116 link
    Cassette Shimano SLX 11-34
    Rims DT Swiss X1800 Wheelset
    Hubs DT Swiss X1800 Wheelset
    Spokes DT Swiss X1800 Wheelset
    Tires Schwalbe Racing Ralph 2.25
    Saddle SDG
    Seatpost Integrated Mast
    Seat Post Diameter 30.9
    Seatpost Clamp
    Rear Dropout / Hub Dimensions 10x135mm QR or 12x142mm thru axle
    Max. Tire Size 2.5
    Bottle Cage Mounts Yes
    Colors Black/Turquoise, Turquoise/White
    Warranty 5 year manufacturer's warranty
    Weight

    N/A

    Miscellaneous
    Price $4650.00
    More Info Yeti website
