2010 Yeti AS-R Carbon Bike (discontinued)

Discontinued
2010 Yeti AS-R Carbon Bike yeti-asr-carbon
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

Specifications

Model Year 2010
Riding Type Cross Country, Trail
Sizes and Geometry

S, M, L View Geometry

Size S M L
Top Tube Length 22.6 23.6 24.6
Head Tube Angle 68 68 68
Head Tube Length 4 4.5 5.3
Seat Tube Angle 72 72 72
Seat Tube Length 27.6 28.3 30.7
Bottom Bracket Height 13 13 13
Chainstay Length 16.9 16.9 16.9
Wheelbase 42.8 43.8 44.9
Standover 27.8 27.8 28.1
Reach
Stack
Frame Material Carbon
Rear Travel 98mm
Rear Shock Fox RP23 (6.5x1.5)
Fork Fox F100 RLC FIT 15mm
Fork Travel 100
Head Tube Diameter 1 1/8-inch
Headset Cane Creek S3
Handlebar Easton MonkeyLite
Stem Thomson X4
Grips Yeti Lock-on
Brakes Shimano XT 160mm rotors
Brake Levers Shimano XT
Shifters Shimano XT
Front Derailleur Shimano XT
Rear Derailleur Shimano XTR SGS Shadow
ISCG Tabs No
Chainguide N/A
Cranks Shimano XT
Chainrings 22/32/42
Bottom Bracket Shimano
Pedals
Chain Shimano, 116 link
Cassette Shimano SLX 11-34
Rims DT Swiss X1800 Wheelset
Hubs DT Swiss X1800 Wheelset
Spokes DT Swiss X1800 Wheelset
Tires Schwalbe Racing Ralph 2.25
Saddle SDG
Seatpost Integrated Mast
Seat Post Diameter 30.9
Seatpost Clamp
Rear Dropout / Hub Dimensions 10x135mm QR or 12x142mm thru axle
Max. Tire Size 2.5
Bottle Cage Mounts Yes
Colors Black/Turquoise, Turquoise/White
Warranty 5 year manufacturer's warranty
Weight

N/A

Miscellaneous
Price $4650.00
More Info Yeti website
