2012 Trek Superfly 100 AL Pro Bike (discontinued)

Discontinued
2012 Trek Superfly 100 AL Pro Bike 23375
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

    Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

    Vital MTB Retail Partners:
    Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

    Specifications

    Model Year 2012
    Riding Type Cross Country, Trail
    Sizes and Geometry

    15.5, 17.5, 19, 21, 23 View Geometry

    Size 15.5 17.5 19 21 23
    Top Tube Length 22.2 23.5 24.3 25.1 26
    Head Tube Angle 71 71 71 71 70.1
    Head Tube Length 4.1 4.5 4.9 5.3 5.7
    Seat Tube Angle 73.6 73.6 73.6 73.6 73.6
    Seat Tube Length 15.5 17.5 19 21 23
    Bottom Bracket Height 12.8 12.8 12.8 12.8 12.8
    Chainstay Length 17.8 17.8 17.8 17.8 17.8
    Wheelbase 42.7 44 44.8 45.4 46.5
    Standover 28.1 29.6 31 32.9 34.8
    Reach
    Stack
    Frame Material Alpha Platinum Aluminum main frame & stays w/ABP Convert, Flow Mold Carbon swing link, G2 Geometry, E2 tapered head tube, replaceable derailleur hanger, 110mm travel
    Rear Travel 110mm
    Rear Shock Fox Performance Series Float RP-23 Adaptive Logic, Boost Valve, 3-position ProPedal, rebound; 7.25x1.75", tuned by Trek in California
    Fork Fox Evolution Series 32 Float 29 RL, air spring, lockout, rebound, custom G2 Geometry, 51mm offset crown, E2 tapered steerer, 15QR thru axle, 100mm travel
    Fork Travel 100mm
    Head Tube Diameter 1.5 Taper
    Headset FSA NO.57E, E2, ACB sealed bearings
    Handlebar Bontrager Race Lite Low Riser, 31.8mm, 5mm rise, 9 degree sweep
    Stem Bontrager Race X Lite, 31.8mm
    Grips Bontrager Race Lite, lock-on
    Brakes Shimano Deore XT M785 hydraulic disc brakes
    Brake Levers Shimano Deore XT M785 hydraulic disc brakes
    Shifters Shimano Deore XT M780, 10 speed
    Front Derailleur Shimano Deore XT, direct mount
    Rear Derailleur Shimano Deore XT M780 Shadow
    ISCG Tabs
    Chainguide
    Cranks Shimano Deore XT M785, 38/26
    Chainrings 38/26
    Bottom Bracket
    Pedals
    Chain
    Cassette Shimano SLX HG81-10 11-36, 10 speed
    Rims Bontrager Race Lite TLR Disc 29 wheel system,Tubeless Ready
    Hubs 15mm FCC front hub, 142x12mm rear hub, 28 hole,
    Spokes
    Tires Bontrager 29-1 Team, 29x2.2"
    Saddle Bontrager Evoke 3, titanium rails
    Seatpost Bontrager Rhythm Elite, 31.6mm, zero offset
    Seat Post Diameter 31.6
    Seatpost Clamp
    Rear Dropout / Hub Dimensions 142x12
    Max. Tire Size
    Bottle Cage Mounts
    Colors Metallic Black/True Blue
    Warranty
    Weight

    N/A

    Miscellaneous
    Price $3729.99
    More Info Trek website
