2012 Trek Lush S Bike (discontinued)

Discontinued
2012 Trek Lush S Bike 26907
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

    Need more info? View our Cross Country Mountain Bikes buyer's guide.

    Vital MTB Retail Partners:
    Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

    Specifications

    Model Year 2012
    Riding Type Cross Country
    Sizes and Geometry

    14.5, 15.5, 16.5, 17.5 View Geometry

    Size 14.5 15.5 16.5 17.5
    Top Tube Length 20.8 21.3 22.1 22.8
    Head Tube Angle 68 68 68 68
    Head Tube Length 4.8 4.8 5.1 5.1
    Seat Tube Angle 73.5 73.5 73.5 73.5
    Seat Tube Length 14.5 15.5 16.5 17.5
    Bottom Bracket Height 13.3 13.3 13.3 13.3
    Chainstay Length 16.9 16.9 16.9 16.9
    Wheelbase 41.8 42.4 43.2 43.9
    Standover 27 27 27 27
    Reach
    Stack
    Frame Material WSD Alpha Platinum Aluminum
    Rear Travel 120mm
    Rear Shock Fox Performance Series Float RP-2 w/DRCV, ProPedal, rebound; 6.75x1.75", tuned by Trek in California
    Fork RockShox Reba RL w/Dual Air spring, Motion Control lockout, E2 tapered steerer, 15mm thru axle, 120mm travel
    Fork Travel 120mm
    Head Tube Diameter 1.5 Taper
    Headset FSA NO.57E, E2, ACB sealed bearings
    Handlebar Bontrager Low Riser, 31.8mm, 15mm rise, 9 degree sweep
    Stem Bontrager Race Lite, 31.8mm
    Grips ESI Racer’s Edge
    Brakes Shimano Deore M596 hydraulic disc brakes
    Brake Levers Shimano Deore M596 hydraulic disc brakes
    Shifters Shimano Deore M591, 10 speed
    Front Derailleur Shimano Deore
    Rear Derailleur Shimano SLX M663 Shadow
    ISCG Tabs
    Chainguide
    Cranks FSA Comet, 42/32/24
    Chainrings 42/32/24
    Bottom Bracket
    Pedals
    Chain
    Cassette Shimano HG62-10 11-36, 10 speed
    Rims Bontrager AT-850 disc 32-hole rims
    Hubs Shimano M475 alloy hubs;
    Spokes
    Tires Bontrager XR4, wire bead, 26x2.2"
    Saddle Bontrager Evoke 1 WSD
    Seatpost Bontrager SSR, 31.6mm, 20mm offset
    Seat Post Diameter 31.6
    Seatpost Clamp
    Rear Dropout / Hub Dimensions 135x5
    Max. Tire Size
    Bottle Cage Mounts
    Colors Crystal Pearl White
    Warranty
    Weight

    N/A

    Miscellaneous
    Price $2419.99
    More Info Trek website
