2012 Trek Fuel EX 9 Bike (discontinued)

Discontinued
2012 Trek Fuel EX 9  Bike 21924
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

    Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

    Vital MTB Retail Partners:
    Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

    Specifications

    Model Year 2012
    Riding Type Cross Country, Trail
    Sizes and Geometry

    15.5, 17.5, 18.5, 19.5, 21.5 View Geometry

    Size 15.5 17.5 18.5 19.5 21.5
    Top Tube Length 21.7 23.2 24 24.7 25.4
    Head Tube Angle 68 68 68 68 68
    Head Tube Length 4.5 5.2 5.7 5.7 6.4
    Seat Tube Angle 72.5 72.5 72.5 72.5 72.5
    Seat Tube Length 15.5 17.5 18.5 19.5 21.5
    Bottom Bracket Height 13.3 13.3 13.3 13.3 13.3
    Chainstay Length 16.9 16.9 16.9 16.9 16.9
    Wheelbase 42.3 42.9 44.7 45.4 46.1
    Standover 29.2 29.4 29.5 29.6 29.9
    Reach
    Stack
    Frame Material Alpha Platinum Aluminum
    Rear Travel 120mm
    Rear Shock Fox Performance Series Float RP-3 w/DRCV, Boost Valve, 3-position Climb-Ride-Descend ProPedal, rebound; 7.25x2.0", tuned by Trek in California
    Fork Fox 32 Float FIT RLC, Trek DRCV air spring, Kashima coat, compression, lockout, rebound, E2 tapered steerer, 15QR thru axle, 120mm travel, tuned by Trek in California
    Fork Travel 120mm
    Head Tube Diameter 1.5 Taper
    Headset FSA NO.57E, E2, ACB sealed bearings
    Handlebar Bontrager Race Lite Low Riser, 31.8mm, 15mm rise, 9 degree sweep
    Stem Bontrager Race Lite, 31.8mm
    Grips Bontrager Race Lite, single lock-on
    Brakes Shimano M785 hydraulic disc brakes
    Brake Levers Shimano M785 hydraulic disc brakes
    Shifters Shimano Deore XT M780, 10 speed
    Front Derailleur Shimano Deore XT
    Rear Derailleur Shimano XTR M980 Shadow
    ISCG Tabs
    Chainguide
    Cranks Shimano Deore XT M780, 42/32/24
    Chainrings 42/32/24
    Bottom Bracket
    Pedals
    Chain
    Cassette Shimano Deore XT M771-10 11-36, 10 speed
    Rims Bontrager Rhythm Elite TLR Disc wheel system, Tubeless Ready
    Hubs 15mm front hub, 142x12mm rear hub, 28 hole,
    Spokes
    Tires Bontrager XR4 Team, 26x2.2"
    Saddle Bontrager Evoke 2, chromoly rails
    Seatpost Bontrager Rhythm Elite, 31.6mm, zero offset
    Seat Post Diameter 31.6
    Seatpost Clamp
    Rear Dropout / Hub Dimensions 142x12
    Max. Tire Size
    Bottle Cage Mounts
    Colors Raw Tint Dark
    Warranty
    Weight

    N/A

    Miscellaneous
    Price $3939.99
    More Info Trek website
