2010 Trek EX 7 Bike

Average User Rating:
2010 Trek EX 7 Bike fuelex7_titanium
Vital MTB Retail Partners:
Chain Reaction Bicycles Bob's Bicycles Contour REI The House
CCS Vans Jenson U.S.A. GoPro

Compare to other Bikes

Vital MTB Retail Partners:
Chain Reaction Bicycles Bob's Bicycles Contour REI The House
CCS Vans Jenson U.S.A. GoPro

Need more info? View our Cross Country Mountain Bikes or Trail / All-Mountain Mountain Bikes buyer's guides.

Specifications
Model Year 2010
Riding Type Cross-Country, Trail
Sizes and Geometry

S, (15.5), M, (17.5), M, (18.5), L, (19.5), XL, (21.5) View Geometry

Size S, (15.5) M, (17.5) M, (18.5) L, (19.5) XL, (21.5)
Top Tube Length 22.4 23.2 24.0 24.7 25.4
Head Tube Angle 69 69 69 69 69
Head Tube Length 4.4 5.0 5.4 5.6 6.2
Seat Tube Angle 72.5 72.5 72.5 72.5 72.5
Seat Tube Length
Bottom Bracket Height 13.3 13.3 13.3 13.3 13.3
Chainstay Length 16.9 16.9 16.9 16.9 16.9
Wheelbase 41.9 43.4 44.2 44.9 45.7
Standover
Reach
Stack
Frame Material Alpha Red Aluminum w/ABP Race, Full Floater, E2 tapered head tube, magnesium EVO Link, oversized pivot bearings, replaceable derailleur hanger
Rear Travel 120mm
Rear Shock Fox Float RP-2 w/XV Air Can, Pro Pedal, rebound; 7.0x2.0"
Fork Fox 32 F-Series RL w/air spring, rebound, alloy steerer
Fork Travel 120mm
Head Tube Diameter
Headset FSA NO.57E, E2, ACB sealed bearings
Handlebar Bontrager Race Riser, 40mm rise
Stem Bontrager Race Lite, 7 degree
Grips
Brakes Avid Juicy 3.5, hydraulic disc
Brake Levers Avid Juicy 3.5
Shifters SRAM X.5 trigger
Front Derailleur Shimano Deore
Rear Derailleur SRAM X.7
ISCG Tabs No
Chainguide No
Cranks Shimano M542
Chainrings 44/32/22
Bottom Bracket
Pedals Shimano M505, clipless
Chain
Cassette SRAM PG950 11-32, 9 speed
Rims Bontrager Duster rims
Hubs Bontrager Select front hub, M525-L rear hub
Spokes
Tires Bontrager XDX, 26x2.2"
Saddle Bontrager Race
Seatpost Bontrager Race, 5mm offset
Seat Post Diameter 31.6mm
Seatpost Clamp
Rear Dropout / Hub Dimensions
Max. Tire Size
Bottle Cage Mounts
Colors
Warranty Limited Warranty
Weight

N/A

Miscellaneous Trek fork and shock sag meter
Price $2049.99
More Info Trek website
