2014 Specialized Status I Bike

2014 Specialized Status I Bike Bike - Specialized Status I - Gloss Red:White:Black
C70_black C70_moto_orange C70_cyan
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

Need more info? View our Freeride Mountain Bikes or Downhill Mountain Bikes buyer's guides.

Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Specifications

Model Year 2014
Riding Type Freeride, Downhill
Sizes and Geometry

S, M, L View Geometry

Size S M L
Top Tube Length 22.0 23.0 23.9
Head Tube Angle 64.5° 64.5° 64.5°
Head Tube Length 4.7 4.7 4.7
Seat Tube Angle 75° 75° 75°
Seat Tube Length 15.5 16.5 18.0
Bottom Bracket Height 14.0 14.0 14.0
Chainstay Length 16.8 16.8 16.8
Wheelbase 45.8 46.8 47.8
Standover 29.4 29.3 29.9
Reach 16.5 16.7 17.7
Stack 25.4 25.4 25.4
Frame Material M4 Alloy Hydroformed Tubing
Rear Travel 200mm
Rear Shock X-Fusion Vector R, Coil Over with Piggy Back, Adjust Rebound, 8.5x2.5", Spring Rate XS: 350, S: 400, M: 450, L: 500
Fork X-Fusion Vengeance R, Coil Spring, Tapered Alloy Steerer, Rebound Adjust, 20mm Thru-Axle
Fork Travel 170mm
Head Tube Diameter 1-1/2"
Headset Semi-Integrated Alloy Cups for 1-1/2" Headtube and 1-1/8" Steerer, Cartridge Bearings
Handlebar Specialized DH, Low-Rise, 6061 Alloy, 780mm Wide, 9° Backsweep, 6° Upsweep, 31.8mm
Stem Specialized P.Series MTB, Forged Alloy, 4-Bolt, 40mm Length, 31.8mm Clamp
Grips Specialized Sip Grip, Light Lock-On, Half-Waffle Aramid-Infused, S/M: Regular, Others: XL Thickness
Brakes Avid Elixir 1, Metallic Pad, 200mm Front Rotor / 180mm Rear Rotor
Brake Levers Avid Elixir 1 R, Hydraulic Disc, Tool-Less Reach Adjust
Shifters SRAM X4, 8-Speed, Trigger
Front Derailleur N/A
Rear Derailleur SRAM X7, 9-Speed, Short Cage
ISCG Tabs ISCG
Chainguide Status
Cranks Truvativ Ruktion, 165mm
Chainrings 34 Tooth Steel, 4-Bolt, Compact 104mm Pattern
Bottom Bracket Truvativ Howitzer XR, Oversize Sealed Outboard Cartridge Bearings, 73mm Shell
Pedals Alloy Platform, 9/16"
Chain KMC X-8, 8-Speed, Reusable Missing Link
Cassette SRAM PG-830, 8-Speed, 11-32 Tooth
Rims P.Disc, 32mm Wide, 36 Hole
Hubs Specialized Hi Lo Disc, Sealed Cartridge Bearings, 20mm Thru-Axle, 32 Hole Front // Specialized Disc, Bolt-On 135mm, 36 Hole Rear
Spokes Stainless, 14g
Tires Specialized Butcher SX, 2Bliss Ready, 26"x2.3", Foldable Aramid Bead, Dual Compound, 60TPI Front // Specialized Butcher SX, 2Bliss Ready, 26"x2.3", Aramid Bead, Dual Compound, 60 TPI Rear
Saddle Specialized DH, 8mm Steel Rails
Seatpost Specialized 6061 Alloy, 2-Bolt Micro-Adjust, No Offset, 300mm
Seat Post Diameter 30.9mm
Seatpost Clamp Specialized 7050 Hard Anodized Alloy, with QR, 34.9mm, Black
Rear Dropout / Hub Dimensions 135mm
Max. Tire Size
Bottle Cage Mounts N/A
Colors Gloss Black/Charcoal/Cyan, Gloss Cool Grey/Moto Orange, or Gloss Red/White/Black
Warranty Lifetime Frame Subject to Exclusions // 1 Year: Suspension Attachment Points, Suspension Related Equipment (Including Pivot Points, Bushings, Shock Units, Front Suspension Forks, Chain Stays and Seat Stays, Shock Links, Fasteners) // 5 Years: Chain Stays and Seat Stays
Weight

N/A

Miscellaneous
Price $2600.00
More Info Specialized Website
