| Model Year |
2012
|
| Riding Type |
Trail
|
| Sizes and Geometry |
S, M, L, XL
View Geometry
| Size |
S |
M |
L |
XL |
| Top Tube Length |
560mm |
590mm |
620mm |
645mm |
| Head Tube Angle |
66.5° |
66.5° |
66.5° |
66.5° |
| Head Tube Length |
120mm |
130mm |
150mm |
170mm |
| Seat Tube Angle |
70.5° |
70.5° |
70.5° |
70.5° |
| Seat Tube Length |
420mm |
444mm |
467mm |
520mm |
| Bottom Bracket Height |
350mm |
350mm |
350mm |
350mm |
| Chainstay Length |
419mm |
419mm |
419mm |
419mm |
| Wheelbase |
1120mm |
1151mm |
1185mm |
1213mm |
| Standover |
756mm |
761mm |
773mm |
801mm |
| Reach |
404mm |
431mm |
457mm |
477mm |
| Stack |
577mm |
587mm |
605mm |
623mm |
|
| Frame Material |
M5 alloy, fully manipulated frame w/ ORE TT/ DT, tapered and forged HT, ISCG mount, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 160mm travel
|
| Rear Travel |
160mm
|
| Rear Shock |
Custom Fox RP2, ProPedal and rebound adj., 8.5 x 2.125", Enduro eyelet extension
|
| Fork |
RockShox Lyrik R Solo Air, tapered alloy steerer, rebound adj., 20mm Maxle SL thru-axle, 160 mm travel
|
| Fork Travel |
160mm
|
| Head Tube Diameter |
1.5" Taper
|
| Headset |
1-1/8 and 1-1/2" Threadless, Campy style upper with 1-1/2" lower, cartridge bearings
|
| Handlebar |
Specialized All-Mountain low-rise bar, 7050 alloy, 720mm wide, 8º backsweep, 6º upsweep, 31.8mm
|
| Stem |
Specialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise, S: 60 M: 60, L: 75 and XL: 90
|
| Grips |
Specialized lock-on, S/M: Grappler, Others: Grappler XL
|
| Brakes |
Custom Avid Elixir 7 SL, hydraulic disc, alloy backed semi-metallic pad, HS-1 rotor, 200mm rotor Custom Avid Elixir 7 SL, hydraulic disc, alloy backed semi-metallic pad, HS-1 rotor, 180mm rotor
|
| Brake Levers |
Custom Avid Elixir 7 SL hydraulic, tool-less reach adj., w/MatchMaker clamp
|
| Shifters |
SRAM X7, 10-speed, aluminum trigger, w/MatchMaker clamp
|
| Front Derailleur |
SRAM X7, 10-speed, S1 direct mount for DMD
|
| Rear Derailleur |
SRAM X9, 10-speed, mid cage
|
| ISCG Tabs |
|
| Chainguide |
|
| Cranks |
Custom SRAM S-1250, 10-speed AM double, GXP spindle, with shift guide, S: 170mm, others: 175mm
|
| Chainrings |
36/24, w/ chainguide
|
| Bottom Bracket |
SRAM GXP, outboard bearing
|
| Pedals |
|
| Chain |
KMC X-10, 10-speed, w/ reusable Missing Link, nickel plates
|
| Cassette |
SRAM 10-speed, 11-36t
|
| Rims |
Roval 26, 28mm w/ eyelets, 32h
|
| Hubs |
Specialized Hi Lo disc, laser-etched logo, sealed cartridge bearing, 20mm thru-axle, 32h Specialized Hi Lo 142+ disc, laser-etched logo, double-sealed cartridge bearing, 12mm thru-axle, 32h
|
| Spokes |
DT Swiss Industry stainless 2.0, (14g)
|
| Tires |
Specialized Butcher Control, 60 TPI, 2Bliss Ready, aramid bead, dual-compound, 26x2.3" Specialized Purgatory Control, 60 TPI, 2Bliss Ready aramid bead, dual compound, 26x2.2"
|
| Saddle |
Henge Comp, hollow Cr-Mo rails, 143mm width
|
| Seatpost |
2014 butted alloy, single bolt setback, 30.9mm, S/M: 350mm, others: 400mm
|
| Seat Post Diameter |
30.9
|
| Seatpost Clamp |
34.9mm clamp ID, 7050 hard anodized alloy collar w/ QR, black
|
| Rear Dropout / Hub Dimensions |
142 x 12
|
| Max. Tire Size |
|
| Bottle Cage Mounts |
|
| Colors |
Satin Charcoal/Black
|
| Warranty |
|
| Weight |
N/A
|
| Miscellaneous |
|
| Price |
$3300.00
|
| More Info |
Specialized website |
