2014 Santa Cruz Superlight 29 R XC 29 Bike

2014 Santa Cruz Superlight 29 R XC 29 Bike 2013 SUPERLIGHT29catalogflat
C70_2013_superlight29catalogflat C70_detail5 C70_detail3 C70_detail2 C70_detail1 C70_superlight29_detail_02 C70_superlight29_detail_01 C70_superlight29_detail_03
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications

Model Year 2014
Riding Type Cross Country
Sizes and Geometry

S, M, L, XL View Geometry

Size S M L XL
Top Tube Length 22.2 23.0 24.0 25.0
Head Tube Angle 71° 71° 71° 71°
Head Tube Length 3.5 3.9 3.9 4.3
Seat Tube Angle 73.5° 73.5° 73.5° 73.5°
Seat Tube Length 16.5 17.5 19.5 21.0
Bottom Bracket Height 13.1 13.1 13.1 13.1
Chainstay Length 17.5 17.5 17.5 17.5
Wheelbase 42.6 43.6 44.7 45.6
Standover 27.3 27.5 29.3 29.6
Reach 15.2 15.9 16.9 17.8
Stack 23.6 23.9 23.9 24.3
Frame Material Hydroformed Aluminum Tubing
Rear Travel 100mm
Rear Shock Fox Float CTD Adjust
Fork RockShox Recon Silver TK 29 100 Standard (Upgrade to Fox 32 Float 29 CTD O/C 100 or Fox 32 Float 29 CTD O/C 120 Options)
Fork Travel 100mm
Head Tube Diameter Tapered
Headset Cane Creek 10
Handlebar Race Face Ride Flat 710mm
Stem Race Face Ride 70mm or 80mm
Grips Lizard Skin 494
Brakes Shimano M615 (Deore) with 160mm Rotors
Brake Levers Shimano
Shifters Shimano M670 (SLX) 10-Speed
Front Derailleur Shimano M611 or 610 (Deore)
Rear Derailleur Shimano M675 SGS (SLX) Shadow Plus
ISCG Tabs
Chainguide
Cranks Shimano M610 (Deore) 10-Speed
Chainrings 24/32/42 Tooth
Bottom Bracket 73mm Threaded
Pedals N/A
Chain Shimano HG 75 10-Speed
Cassette Shimano HG 81, 11-36 Tooth (SLX) 10-Speed
Rims WTB ST i19 TCS
Hubs Sram MTH716 15mm Front and Shimano M756 or Sram MTH 746 Rear
Spokes DT 14 Gauge, Brass Nipples
Tires Maxxis Ikon 2.2" Tubeless Ready Kevlar
Saddle WTB Volt Race
Seatpost Race Face Ride 375mm
Seat Post Diameter 30.9mm
Seatpost Clamp
Rear Dropout / Hub Dimensions
Max. Tire Size 2.3”
Bottle Cage Mounts Yes
Colors Burnt Orange or Black
Warranty Five Year
Weight

N/A

Miscellaneous
Price $2623.00
