2013 Norco Sight 3 Bike

2013 Norco Sight 3 Bike 064430-13-02-sight3-blue
C70_064430_13_02_sight3_blue C70_064430_13_01_sight3_grey_green
Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

    Need more info? View our Trail Mountain Bikes buyer's guide.

    Vital MTB Retail Partners:
    Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

    Specifications

    Model Year 2013
    Riding Type Trail
    Sizes and Geometry

    XS, S, M, L, XL View Geometry

    Size XS S M L XL
    Top Tube Length 21.3 22.2 23.2 24.2 25.2
    Head Tube Angle 67.5° 67.5° 67.5° 67.5° 67.5°
    Head Tube Length 4.3 4.7 5.1 5.5 5.9
    Seat Tube Angle 74° 74° 74° 74° 74°
    Seat Tube Length 15.7 15.9 17.1 18.5 20.1
    Bottom Bracket Height 13.4 13.4 13.4 13.4 13.4
    Chainstay Length 16.7 16.7 16.7 16.7 16.7
    Wheelbase 42.6 43.6 44.6 45.7 46.7
    Standover 28.3 28.2 29.6 29.6 30.0
    Reach 14.9 15.8 16.7 17.6 18.5
    Stack 22.0 22.4 22.8 23.1 23.5
    Frame Material Hydroformed Alloy
    Rear Travel 140mm
    Rear Shock Fox Float CTD (No BV)
    Fork Sektor TK Solo Air, 15mm Axle
    Fork Travel 140mm
    Head Tube Diameter 1.5" to 1-1/8" Tapered
    Headset FSA #57B (Tapered Internal)
    Handlebar Norco Rise, XS/SM: 740mm, M/L/XL: 760mm
    Stem Norco Trail, XS/S: 60mm, M/L: 70mm, XL: 80mm
    Grips T-One Lock On
    Brakes Avid Elixer 1 Hydraulic Disc, 180mm Front, 160mm Rear Rotors, 6 Bolt
    Brake Levers G2 CS
    Shifters Shimano Deore 3 Front, Shimano Deore 10 Rear
    Front Derailleur Shimano SLX E Type Chainstay Mount
    Rear Derailleur Shimano Deore Long Cage Shadow (10-Speed)
    ISCG Tabs Yes
    Chainguide
    Cranks Shimano M552 10-Speed
    Chainrings 42/32/22 Tooth
    Bottom Bracket Shimano
    Pedals Norco Alloy Flat with Steel Insert Pins
    Chain Sram PC 1031
    Cassette Shimano HG-62 11-36 Tooth 10-Speed
    Rims Alex DC25 Double Wall 25mm Wide
    Hubs Formula Alloy DC 51 with Disc Front, Formula Alloy DC 22 Rear with QR Axle
    Spokes Black Stainless Steel 2.0
    Tires Continental X King 26"x2.4" Wire Bead
    Saddle Norco Design XC/Trail
    Seatpost Norco Alloy 2014 Double Bolt
    Seat Post Diameter 30.9mm
    Seatpost Clamp Norco Design Alloy QR
    Rear Dropout / Hub Dimensions 135mm x 10mm
    Max. Tire Size
    Bottle Cage Mounts Yes
    Colors Blue or Grey
    Warranty
    Weight

    N/A

    Miscellaneous
    Price $2623.00
    More Info Norco website
