2013 Mondraker Summum Pro Bike

Vital MTB Retail Partners:
Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

Compare to other Bikes

    Need more info? View our Downhill Mountain Bikes buyer's guide.

    Vital MTB Retail Partners:
    Chain Reaction Bicycles Jenson U.S.A. Competitive Cyclist Backcountry

    Specifications

    Model Year 2013
    Riding Type Downhill
    Sizes and Geometry

    L, M, S View Geometry

    Size L M S
    Top Tube Length 24.6 23.6 22.6
    Head Tube Angle 63° (+/-2°) 63° (+/-2°) 63° (+/-2°)
    Head Tube Length
    Seat Tube Angle 73.5° 73.5° 73.5°
    Seat Tube Length 15.0 15.0 15.0
    Bottom Bracket Height +10mm Drop +10mm Drop +10mm Drop
    Chainstay Length 17.3-17.9 17.3-17.9 17.3-17.9
    Wheelbase 48.8 47.8 46.9
    Standover
    Reach
    Stack
    Frame Material Summum Stealth Alloy Zero Suspension System FG
    Rear Travel 205mm
    Rear Shock Fox DHX RC2 222x70mm
    Fork Fox 40 RC2 Fit
    Fork Travel 200mm
    Head Tube Diameter 1-1/8”
    Headset Onoff ZS Integrated
    Handlebar Mondraker DH 31.8mm x 780mm
    Stem Onoff Stoic DH Integrated FG 10mm
    Grips Onoff Diamond Close End
    Brakes Formula RX 203mm
    Brake Levers Formula RX
    Shifters Sram Trigger X7
    Front Derailleur N/A
    Rear Derailleur Sram X9 Short Cage 10-Speed
    ISCG Tabs
    Chainguide E.13 LS1
    Cranks Truvativ Hussefelt 1.0, 165mm
    Chainrings 38 Tooth
    Bottom Bracket Truvativ Howitzer XR
    Pedals N/A
    Chain Sram PC-1031 10-Speed
    Cassette Sram PG-1030 11-26 Tooth 10-Speed
    Rims DT F630
    Hubs MDK Disc Pro DH, 20mm Front
    Spokes CN Stainless Butted
    Tires Schwalbe Big Betty 26"x2.4"
    Saddle SDG I-Beam I-Fly
    Seatpost SDG I-Beam SP-751 300mm
    Seat Post Diameter 31.6mm
    Seatpost Clamp
    Rear Dropout / Hub Dimensions 12x150mm
    Max. Tire Size
    Bottle Cage Mounts No
    Colors Red with Black
    Warranty
    Weight

    36 lb 13.1 oz (16.7 kg)

    Miscellaneous
    Price N/A
