2013 Cannondale Trail 5 Bike

Views:
2013 Cannondale Trail 5 Bike 2013 Cannondale Trail SL 5 (black)
C70_2013_cannondale_traill_sl_5_black C70_2013_cannondale_traill_sl_5_green
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications

Product Cannondale Trail 5 Bike
Model Year 2013
Riding Type Cross Country
Rider Unisex
Sizes and Geometry
S / 15", M / 17", L / 18.7", XL / 20.7", XXL / 22.4" View Geometry
Size S / 15" M / 17" L / 18.7" XL / 20.7" XXL / 22.4"
Top Tube Length 21.7 23 24.2 24.8 25.1
Head Tube Angle 70° 70° 70° 70° 70°
Head Tube Length 4.5 4.5 4.5 5.7 5.7
Seat Tube Angle 73.5° 73.5° 73° 72.5° 72.5°
Seat Tube Length 15 17 18.7 20.7 22.4
Bottom Bracket Height 11.4 11.4 11.4 11.4 11.4
Chainstay Length 16.7 16.7 16.7 16.7 16.7
Wheelbase 41.2 42.6 43.4 44 44.3
Standover 29.3 30.2 31 32.5 33.3
Reach 14.7 16.3 17 17.3 17.6
Stack 23.5 24 24.5 25 25.5
Frame Material Aluminum
Frame Material Details Double Butted 6061 Alloy, SAVE
Rear Travel Hardtail
Rear Shock N/A
Fork SR Suntour XCM-HLO, Coil Spring with Hydraulic Lock Out, 1-1/8"
Fork Travel 100mm
Head Tube Diameter 1-1/8Â
Headset Tange Seiki ER2 Slim Stack
Handlebar Cannondale C4, 660mm x 30mm, 6061 Alloy
Stem Cannondale C4, 1-1/8", 31.8mm, 7 Degree
Grips Cannondale Dual-Density Grip
Brakes Shimano BR-M375 Mechanical Disc, 160mm/160mm
Brake Levers
Drivetrain 3x
Shifters Shimano Altus, 34.9 Clamp
Front Derailleur Shimano Altus, 34.9 Clamp
Rear Derailleur Shimano Acera
ISCG Tabs
Chainguide
Cranks Shimano, FC-M311-8
Chainrings 42/32/22 Tooth
Bottom Bracket Shimano ES-25 Octalink
Pedals FPD Platform
Chain KMC X8
Cassette Shimano HG31-8, 11-32 Tooth, 8-Speed
Wheel Size 26"
Rims Alex DC4.5, Double Wall, 32 Hole
Hubs Cannondale C4
Spokes Stainless Steel, 14g
Tires Kenda Small Block 8, 26" x 2.1"
Saddle Cannondale Stage 3
Seatpost Cannondale C4, 350mm (S, M) 400mm (L,XL,XXL)
Seat Post Diameter 31.6mm
Seatpost Clamp
Rear Dropout / Hub Dimensions
Max. Tire Size
Bottle Cage Mounts Yes
Colors Black or Green
Warranty
Weight N/A
Miscellaneous
Price $780
More Info

Cannondale website
